Non Contact Wireless Liquid Radar Level Switch Sensor
US$ 900 - 1400
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Yunyi
Place of Origin:
China
Model Number:
YD322-C
Payment & Shipping
Payment Methods:
Port of Shipment:
any port of China
Delivery Detail:
10 days
Related Products
-
Fluid Level Measurement Radar Level TransmitterUS$ 900 - 1400MOQ: 1 Piece -
Radar Level Switch Level Transmitter for Water TankUS$ 900 - 1400MOQ: 1 Piece
-
Cheap Ultrasonic Water Oil Liquid Level SensorasurementUS$ 140 - 240MOQ: 1 Piece
-
Ultrasonic Water Oil Liquid Level SensorUS$ 140 - 240MOQ: 1 Piece
-
Liquid Water Level Meter Sensor With DisplayUS$ 40 - 75MOQ: 1 Piece
Brand Name
Yunyi
Place of Origin
China
Model Number
YD322-C
Principle of solid particle radar level meter ,rader level transmitter NYRD809:
Radar level meter emits a very narrow microwave pulse, the pulse to the speed of light in the space, encountered the surface of the measured medium, part of its energy is reflected back, the same antenna to receive. The time interval between the transmitting pulse and the receiving pulse is proportional to the distance from the antenna to the surface of the measured medium to calculate the distance from the antenna to the surface of the measured medium.
Features of solid particle radar level meter ,rader level transmitter NYRD809:
Radar level meter with up to 26GHZ launch frequency, which has:
- Beam angle is small, energy concentration, with greater resistance to interference, greatly improving the measurement accuracy and reliability;
- antenna size is small, easy to install and install dust cover and other antenna protection device;
- measuring the blind area is smaller, for small cans measurement will also achieve good results;
- Wavelength is shorter, more suitable for small particle material level measurement.
- With advanced microprocessors and unique EchoDiscovery echo processing technology, the radar level meter can be applied to a variety of complex conditions. The same time as the above-
- The use of pulse mode, the radar level meter transmission power is very low, can be installed in a variety of metal, non-metallic containers, the human body and the environment are not hurt.
Radar level meter with up to 26GHZ launch frequency, which has:
- Beam angle is small, energy concentration, with greater resistance to interference, greatly improving the measurement accuracy and reliability;
- antenna size is small, easy to install and install dust cover and other antenna protection device;
- measuring the blind area is smaller, for small cans measurement will also achieve good results;
- Wavelength is shorter, more suitable for small particle material level measurement.
- With advanced microprocessors and unique EchoDiscovery echo processing technology, the radar level meter can be applied to a variety of complex conditions. The same time as the above-
- The use of pulse mode, the radar level meter transmission power is very low, can be installed in a variety of metal, non-metallic containers, the human body and the environment are not hurt.
Specifications of solid particle radar level meter ,rader level transmitter NYRD809:
Range: 35 meters
Accuracy:+/-3MM
Temperature: -40-130 degrees
Pressure: -0.1--4MPA
Connection: thread flange
Output: 4~20mA /Hart/M0dbus
Power supply: 24VDC / 220VAC
Temperature: -40-130 degrees
Pressure: -0.1--4MPA
Connection: thread flange
Output: 4~20mA /Hart/M0dbus
Power supply: 24VDC / 220VAC
Application: solid particle and dust
Our service:
We accept all kinds of payment terms like L/C T/T ,we protect all buyers .I
OEM & Customize
We support OEM service, you can make goods according to your samples , color, material and so on for the custom.
Online Service
It is a twenty-four-hour service that allows you to send information at any time of the day or night.we will reply within 12 hours.
Design Team
we have design team to make customized products , you can send your samples or drawing to us and our team will make samples for you . also we can design products according to your description.
