A force sensor used on the instrument. It can be applied to the measured object gravity by a certain percentage into a measurable output signal. Considering the influence of gravity acceleration and air buoyancy on the conversion of different use sites, the performance indexes of the load cell mainly include linearity error, hysteresis error, repeatability error, creep, zero temperature characteristic and sensitivity temperature characteristic. In a variety of weighing and quality metering systems, the integrated error is often used to comprehensively control the sensor accuracy and to correlate the error band with the instrument error in order to use a load cell corresponding to an accuracy meter.
The load point is not sensitive to change, anti-partial load performance, inherent linear good, easy to install, load sensor fixed does not rotate
Mainly used in the field of all kinds of electronic weighing equipment, industrial control, online control, overload safety alarm, material testing machine, such as electronic truck scale, electronic scales, electronic forklift, dynamic axis scale, electronic crane scale , Electronic price scale, stainless steel hopper scale, electronic balance, electronic rail scale, batching scales, canned scales, etc.
Parameters:
Rated Load（kg.） |
60, 100, 150, 200, 250, 300,400,500....1000 |
Rated Output (mV/V) |
2.0±0.2 |
Zero Balance (%R.O) |
±1 |
Comprehensive Error (%R.O) |
±0.02 |
Creep/30min (%R.O) |
±0.02 |
Compensated temp. Range (℃) |
-10~+40 |
Operating temp. Range (℃) |
-20~+70 |
Temp.effect/10℃ on span （%R.O./10 ℃） |
±0.02 |
Temp.effect/10℃ on zero （%R.O./10 ℃） |
±0.02 |
Recommended excitation voltage （VDC） |
10 |
Input impedance |
410±10 |
Output impedance |
350±3 |
Insulation resistance （M） |
>5000 |
Safe overload（%R.C） |
150 |
Ultimate overload （%R.C） |
200 |
Material |
Aluminum |
Degree of protection |
IP65 |
