DC-DC Converter 1W 1000VDC Isolation Dual Output
Negotiable
MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Sunyuan
Place of Origin:
China
Model Number:
AxxxxS-1W
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen China
Delivery Detail:
5 days
Related Products
-
3-24VDC Fixed Input, Unregulated Dual Voltage Output DC DC Converter IC E0512D-1WNegotiableMOQ: 2 Pieces -
Wide Volt. Range Input, High Volt. Output Step-up DC-DC Converter Grb12100d-10W-BNegotiableMOQ: 2 Pieces
-
36V Input DC DC Converter With Dual OutputNegotiableMOQ: 2 Pieces
-
0.2-2W Fixed Input, Regulated Dual Output DC/DC Converter (WRE Series)NegotiableMOQ: 2 Pieces
-
(2: 1) Wide Input Range 36V-72 48V 5W DC-DC ConverterNegotiableMOQ: 2 Pieces
Brand Name
Sunyuan
Place of Origin
China
Model Number
AxxxxS-1W
1W-3W DC DC converters with FIxed Input and Unregulated Output1KV Isolation
AxxxxS/D-xW Series
AxxxxS/D-xW Series
A Series DC-DC Converter Features:
-High power density
-SIP 7 pin/DIP 14 pin package
-Dual/single output
-Industrial standard pin-out
-Non heat sink required
-1kvdc isolation
-Fixed input, Unregulated output
-PCB mounting
-Efficiency: 72%~86%
-Temperature range: -40 to 85 centigrade
-Available inputs: 5, 12, 15 and 24 VDC
-Available outputs: (+/-) 3.3, 5, 9, 12, 15 and 18 VDC
-Custom service available
A Series DC-DC Converter Applications:
-Ground loop elimination
-Industrial process control
-RS232/485 isolation digital interface system
-Electrical superision and biomedical equipment.
A Series Fixed Input Unregulated Output DC-DC Converter Size:
| Part Number | Input Voltage (VDC) | Output | Efficiency (%, Typ. ) |
Package | Capacitor Load Max (uF) |
|||
| Range | Nominal | Max. | Current (mA) | Voltage (VDC) | ||||
| A0505S-1W | 4.5~5.5 | 5 | 5.5 | ± 100 | ± 5 | 71 | SIP/DIP | 4.7 |
| A0512S-1W | 5 | 5.5 | ± 42 | ± 12 | 80 | SIP/DIP | 1 | |
| A0515S-1W | 5 | 5.5 | ± 34 | ± 15 | 80 | SIP/DIP | 0.47 | |
| A1205S-1W | 10.8~13.2 | 12 | 13.2 | ± 100 | ± 5 | 80 | SIP/DIP | 4.7 |
| A1212S-1W | 12 | 13.2 | ± 42 | ± 12 | 78 | SIP/DIP | 1 | |
| A2403S-1W | 21.6~26.4 | 24 | 26.4 | ± 150 | ± 3.3 | 75 | SIP/DIP | 4.7 |
| A2405S-1W | 24 | 26.4 | ± 100 | ± 5 | 74 | SIP/DIP | 4.7 | |
| A2412S-1W | 24 | 26.4 | ± 42 | ± 12 | 76 | SIP/DIP | 1 | |
