Brief Introduction
Pet food processing line is used to produce pet food with novel shape,particular taste and color.Scirntific nutrition combination catch up the trend the market.With simple operation,accurate parameter control,the products can be finished in the stipulated temperature, presure,humidity and time.Owing to the reasonable design,special materials,the stability repairs can be guaranteed and ensured.The various shape and taste must meet the different requirements of pet food.This Line consists of mixer,double-screw,extruder,air conveyer,dryer and coating machine.
Pet food processing machine flow chart
Grain grinder system---Mixing system---Twin screw Extrusion system----Drying system----Flavoring system--Packing system
Pet food processing machine Technical parameter
Model Number |
XBF65/70/85/90/95/115/120/135/160 |
Application |
Dog Cat Monkey Pet |
Voltage |
208/220/240/380/400/415/440/480V |
Power(W) |
As per final configuration or user requirement |
Weight |
As per final configuration or user requirement |
Dimension(L*W*H) |
As per final configuration or user requirement |
Certification |
ISO, CE, SGS, BV, TUV |
Warranty |
1 year |
After-sales Service Provided |
Engineers available to service machinery overseas |
Dog feed raw materials |
Corn meal, wheat flour, rice flour de-oil soya flour, etc. |
Capacity |
100-25000kg/hr |
Heating power source |
Electricity, oil-fired burner,gas-fired burner, steam |
Screws quantity |
1 couple (twin-screw) |
Screws material |
38CrMoAl |
Fish feed diameter |
From 1.5mm to 25mm |
Dies |
6 pcs for free |
Inverter brands |
Delta, LS, ABB, Siemens, customizable |
Motor brands |
Siemens |
Dog Food Samples:
Extruder Specifications | ||||
Model |
Installed power |
Real power |
Output |
Dimension |
XBF65 |
70kw |
40kw |
100-150kg/h |
22000*1200*2200mm |
XBF 70 |
90kw |
50KW |
200-240kg/h |
25000*1500*2200mm |
XBF 85 |
120kw |
100kw |
400-500kg/h |
30000*3500*4300mm |
XBF 90 |
135kw |
100kw |
800-1000kg/h |
30000*3500*4300mm |
XBF 120 |
165kw |
115kw |
1000-2000kg/h |
30000*3500*4300mm |
