XSU080218 China Cross Cylindrical Roller Bearing XSU080258 With Mounted Holes Bearing XSU080398 Bearing
US$ 1 - 100000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
OEM
Place of Origin:
China
Model Number:
XSU080218
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
7 days
Related Products
-
YDPB XSU080258 Cross Roller Bearing Manufacturer Turn Table BearingUS$ 1 - 100000MOQ: 1 Piece -
YDPB XSU080318 China Precision Roller Bearing Suppliers Torque Motor BearingUS$ 1 - 100000MOQ: 1 Piece
-
YDPB XSU140544 Cylindrical Roller Bearing Cross Reference INA Standard Slewing RingsUS$ 1 - 100000MOQ: 1 Piece
-
YDPB XSU080398 High Precision Cross Roller Bearings With Mounting Holes for Machine ToolsUS$ 1 - 100000MOQ: 1 Piece
-
YDPB XSU140414 Cross Roller Bearing Price Made in China Rotary Indexing Table MachinesUS$ 1 - 100000MOQ: 1 Piece
Brand Name
OEM
Place of Origin
China
Model Number
XSU080218
Number of Row
Single Row
Precision Rating
P4
Outside Diameter
130, 1024
Bore Size
25.4, 56
Crossed Roller Bearings Parameters
Model number-
Inner ring(mm)-
Outer ring(mm)-
Width(mm)-
Weight(Kg)-
Materials- GCR15/GCR15SiMn
Precision grade- P5/P4/P2
Lubrication type- Grease lubrication
Rotating part- Inner ring/Outer ring
Load direction- Multi-load
Structure- Integrated Inner/Outer Ring
Series Model NO..
XSU080168bearings,XSU080188bearings,XSU080218bearings,XSU080258bearings,XSU080318bearings,XSU080398bearings,
XSU140414bearings,XSU140544bearings,XSU140644bearings,XSU140744bearings,XSU140844bearings,XSU140944 bearings
Applications
Vertical machining center,vibratory grinding unit,tandem roller etc. high precision parts
Structure and Parameters:
| Series |
Model Number |
Main dimensions | Fixing Hole(Outer ing) | Fixing Hole(Inner ing) |
Basic load rating (Axial) |
Basic load rating (Radial) |
Weight Kg |
|||||||
|
Inner ring d(mm) |
Outer ring D(mm) |
Roller pitch circle dp(mm) |
Width B(mm) |
Pitch of holes φLa |
Number na |
Pitch of holes φLi |
Number ni |
Ca KN | Coa KN | Cr KN | Cor KN | |||
| XU | XU050077 | 40 | 112 | 77 | 22 | 97 | 6-φ6.6 | 56 | 6-M8 | 22.4 | 29 | 14.3 | 14.2 | 1.4 |
| XU060094 | 57 | 140 | 94 | 26 | 120 | 6-φ9 | 70 | 6-M8 | 32.5 | 37.5 | 20.7 | 18.4 | 2.4 | |
| XU060111 | 76.2 | 145.79 | 111 | 15.87 | 133.1 | 8-φ6.9 | 88.9 | 8-φ6.9 | 36 | 44.5 | 22.8 | 21.5 | 1.2 | |
| XU080120 | 69 | 170 | 120 | 30 | 148 | 6-φ9 | 90 | 6-M8 | 56 | 53 | 35.5 | 26 | 4 | |
| XU080149 | 101.6 | 196.85 | 149.6 | 22.22 | 177.8 | 16-φ6.9 | 115.8 | 16-φ6.9 | 63 | 66 | 40 | 32.5 | 3.6 | |
| XU120179 | 124.5 | 234 | 179 | 35 | 214 | 12-φ11 | 144.5 | 12-φ11 | 118 | 179 | 75 | 88 | 7 | |
| XU120222 | 140 | 300 | 222 | 36 | 270 | 12-M16 | 170 | 12-φ18 | 133 | 275 | 85 | 131 | 12 | |
| XU160260 | 191 | 329 | 260 | 46 | 305 | 20-φ14 | 215 | 20-φ14 | 212 | 350 | 135 | 173 | 16 | |
| XU080264 | 215.9 | 311 | 264 | 25.4 | 295.3 | 12-φ8.7 | 231.8 | 12-φ8.7 | 85 | 117 | 54 | 57 | 6.9 | |
| XU160405 | 336 | 474 | 405 | 46 | 450 | 30-φ14 | 360 | 30-φ14 | 270 | 550 | 172 | 270 | 25 | |
| XU080430 | 380 | 480 | 430 | 26 | 462 | 20-φ9 | 398 | 20-M10 | 110 | 280 | 70 | 138 | 12 | |
| XU300515 | 384 | 646 | 515 | 86 | 598 | 18-φ26 | 432 | 18-φ26 | 720 | 1370 | 455 | 670 | 115 | |
