Rice Mill Thickness Length Rice Grader

Rice Mill Thickness Length Rice Grader thumbnail-1
Rice Mill Thickness Length Rice Grader thumbnail-2
Rice Mill Thickness Length Rice Grader thumbnail-3
Rice Mill Thickness Length Rice Grader photo-1
Rice Mill Thickness Length Rice Grader photo-2
Rice Mill Thickness Length Rice Grader photo-3
US$ 500 - 2000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
BRT
Place of Origin:
China
Model Number:
VS80
Contact Supplier Request Quote Chat Now
Guangzhou Fengtai Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BRT
Place of Origin China
Model Number VS80
Certification CE, ISO
After-sales Service Provided Engineers available to service machinery overseas
Warranty 1 year
Weight 45KG
Dimension(L*W*H) 1000*200*1000MM
Production Capacity 2-3TON/HOUR
Condition New
Voltage 380V 3-50HZ
Power(W) 1KW


Specifications
MMJP Rice Grader
Series rice grader from 1.0T/h to 6.0T/h.
Reliable Quality;
Competitive Price;
SGS, ISO9001:2008.

MMJP Rice Grader:





Main technical characteristicsThe horizontal rotating rice classifying sieve manufactured by the factory has 4 specifications, the technical characteristics refers to tables 1, 2 and 3.

1. Working conditions and technical index               Table 1



Items

Unit

Type

MMJP63×3

MMJP80×3

MMJP100×3

MMJP 112×3

MMJP 100×4

MMJP 112×4B

Broken rice on entering machine

%

≤35

Flow rate on entering machine

t/h

1.25

2.1

3.3

4.2

3.8

5.2

Special class rice with broken one

%

Broken ride with whole rice

%

Not include the whole rice



2. Technical characteristics                                        Table 2



Items

Unit

MMJP 63×3

MMJP 80×3

MMJP 100×3

MMJP 112×3

MMJP 100×4

MMJP 112×4B

Layer of sieve face

Layer

3

4

Eccentric distance

mm

40

Rotation speed

RPM

150±15 (stepless speed control during running)

Angle of tilt of sieve face

Degree

1.2

Weight of machine

Kg

415

520

615

660

680

730

Power

KW (type)

0.55

(Y801-4)

1.1 (Y908-4)

Dimension

(L×W×H)

mm

1426×740×1276

1625×100×1315

1725×1087×1386

1725×1207×1386

1645×1350×1945

1662×1350×1945



3. Sieve specifications: (6 pcs. Of which 3 as spare parts)       Table 3



Sieve opening (mm)

L×W (mm)

MMJP 63×3

MMJP 80×3

MMJP 100×3

MMJP 112×3

MMJP 100×4

MMJP 112×4B

Φ3.7 Φ3.5 Φ3.0

Φ2.6 Φ2.4 Φ2.0

1090×630

1260×800

1360×1000

1360×1120

1360×995

1360×1120

Product Tags: rice mill , rice grader , length grader
