boron carbide B4C POWDER

C%

17-22

Fe₂O₃%

0.1-0.8

B₄C%

90-99

Molecular Formula

B4C

Density & phase

2.52g/cm3   Solid

Solubility In Water

Insoluble

Melting Point

2450°C

Boiling point

3500°C

Crystal Structure

 Rhombohedral

Mohs Hardness

9.6

Micro Hardness

4950kgf/mm2

2

For Nuclear Industry

 B₄C can be prepared into controlling bars, adjusting bars, accident bars, safety bars, screen bars, radiation resistant B₄C tilts, plate, or neutron absorber(prepared with high B10 content powders),and radiation resistant layer for atomic reactor together with cement which is the most important functional component only next to reactor fuel.

3

For Refractories Industry

 B₄C can be used as anti-oxidation agent for low carbon magnesia carbon brocks and castables. It can be applied in key positions which suffer from serious erosion and high temperature, such as ladle, taphole(nozzle),sliding plate and stopper.

4

For Other Engineering Ceramic Materials

 B₄C can be prepared into nozzles for sand spraying machine and high pressure water cutter, ring seal, mould for ceramics etc

5

For Normal Industry Fields

 B₄C is used to prepare: high grade wear-resistant welding rods to strength the wear resistance of welding face; grinding and polishing materials, water cutting abrasives and polishing materials for diamond abrasives tools; polishing and grinding of jewels.

6

Application of B4C on Electrical Property

 B4C-graphite thermocouple is composed of graphite pipe, B4C bar and BN Lining.In inert gases and vacuum, its service temperature is 2200℃,the linear relation of electric potential difference and temperature is good

7

Application of B4C as Chemical Material

 After being activated nu halogens, B₄C powder can be used as boronation agent of steel and other alloys for boronizing on the steel surface, forming a thin iron boride layer, increasing the strength and wear resistance of the materials.

JIS

JIS#36 JIS#46 JIS#54 JIS#60 JIS#80 JIS#100 JIS#120 JIS#150 JIS#180 JIS#220 JIS#240 JIS#280 JIS#320 JIS#360 JIS$400 JIS#500 JIS#600 JIS#800 JIS#1000 JIS#1200 JIS#1500 JIS#2000 JIS#2500 JIS#3000 JIS#4000 JIS#6000 JIS#8000 -325F #60-150  #80-120

2

20kgs paper bags+pallet

3

20kgs Barrels+pallet
