Home > Products > Welded mesh fence > PVC Coated Curved Welded Wire Mesh Railway Airport Fence Panel
PVC Coated Curved Welded Wire Mesh Railway Airport Fence Panel
- 300 Kilometer / Kilometers per Month
- Tianjin
- T/T L/C D/P D/A
- 7 days
- Spring Snap Hook/Key Chain Snap Hooks/Fashion Snap Hooks
- Aluminum Snap Hook/ spring hook/ carabiner hook
- Stainless Steel AISI304/316 Spring Snap Hook With Screw Carbine Hook With Lock (4mm-14mm)
- Steel Snap Hook, metal carainer spring clip hook
- best snap hook rigging hardware snap hook
- Spring Large Trampoline with safety net
Product Details
Brand Name: | QYM | Place of Origin: | China | Model Number: | welded mesh fence |
Metal Type: | Steel | Feature: | Easily Assembled, Eco Friendly, FSC, Pressure Treated Timbers, Rodent Proof, Rot Proof, Tempered Glass, TFT | Frame Finishing: | Powder Coated |
Pressure Treated Wood Type: | Heat Treated | Frame Material: | Metal |
Product Description
QYM-Welded Mesh Fence
It is an economical version of the panel system, constructed from a welded mesh panel with longitudinal profiles that forms a rigid fence.
The fence panel is welded with high quality low carbon steel wire, surface treated by electrostatic polyester powder spray coating over galvanized materials, then connected with post by suitable clips. Due to its simple structure, easy installation, nice appearance, more and more customers regard welded mesh fence as the preferred common protective fence.
L Steel Material: Q195-Q235
L Color: Darkgreen(RAL6005), other RAL colors, also available as request UV available.
Mesh | Wire Thickness | Surface Treatment | Panel Width | Folds NOS. | Height |
50X200mm Or 55X200mm | 4.50mm Or 5.00mm | Galvanized And Electrostatic polyester powder coated or PVC coated | 2.50m | 2 | 830mm |
2 | 1030mm | ||||
2 | 1230mm | ||||
2 | 1430mm | ||||
3 | 1630mm | ||||
3 | 1830mm | ||||
4 | 2030mm | ||||
4 | 2230mm | ||||
4 | 2430mm |
Mesh | Wire Thickness | Surface Treatment | Panel Width | Folds NOS. | Height |
50X200mm And 50X100mm in folds Or 55X200mm And 55X100mm In folds | 4.50mm Or 5.00mm | Galvanized and Electrostatic polyester Powder Coated or PVC coated | 2.50m | 2 | 1030mm |
2 | 1230mm | ||||
3 | 1530mm | ||||
3 | 1730mm | ||||
4 | 2030mm |
L Steel Material: Q195
L Color: Darkgreen(RAL6005), other RAL colors, also available as request UV available.
Profile | Wall Thickness | Surface Treatment | Length | Base Plate | Rainhat |
50X50mm | 1.50mm - 4.00mm | Galvanized and Electrostatic polyester powder coated | On the basis of panel height | Available | Plastic or Metal |
60X60mm |
Profile | Wall Thickness | Surface Treatment | Length | Base Plate | Rainhat |
60X40mm | 1.50mm - 4.00mm | Galvanized and Electrostatic polyester powder coated | On the basis of panel height | Available | Plastic or Metal |
80X40mm |
Profile | Wall Thickness | Surface Treatment | Length | Base Plate | Rainhat |
50X70mm | 1.20mm Or 1.50mm | Galvanized and Electrostatic polyester powder coated | On the basis of panel height | Available | Plastic |
60X90mm | |||||
70X100mm |
Profile | Wall Thickness | Surface Treatment | Length | Base Plate | Rainhat |
Φ48 | 1.50mm - 3.20mm | Galvanized and Electrostatic polyester powder coated | On the basis of panel height | Available | Plastic or Metal |
Φ60 | |||||
Φ75 |
Variations for post
L In addition to the standard posts many variations are available
L to accommodate site requirements:
L •alternative sections
L •wall fixing plates, cranked posts or base plated
L •cranked or straight extensions for barbed or razor wire
Company Information
Hebei Qianye Metal Product Co., Ltd is a company engaged in production and exportation of metal fence as well as other metal products, such as airport fence, barb wire, chain link fence, concertina razor wire, double wire fence, euro fence, palisade fence, temporary fence, welded mesh, welded mesh fence, wire mesh, etc. Its registered capital is RMB50, 100, 000(about USD 7, 400, 000), covering a land area of 30, 000 square meters.
Service
1>Quality Products:
We follow the policy of Seeking Development through Quality and Establishing Reputation via
Quality Products. We try to meet customers' requirements with excellent quality products.
2>Honest Service:
We offer honest service to customers. We provide products with sincere and excellent service and the most prompt delivery.
3>Innovation:
We have advanced inspection and production equipment and can develop new products to meet the demand of market. We can also accept customized orders. Our strong R&D capability enables us to innovate almost everyday.
Packing & Shipping
1>Panel Packing:
It has soft sponge at the botom of the pallet to avoid the botom fence panel to be damaged by metal pallet.
It has 4 metal corners to keep the pallet be more strong.
It has metal plate under the plastic bandage to avoid the bandage to presure the fence panel.
It has wood plate on the top of pallet to keep the above pallet to de destroyed by the pallet.
2>Post Packing:
The post is covered with plasti cap then packed with plastic flim. Clips packed by set.
3>Accessories:
Plastic bags + carton boxes
FAQ
Q: What's QYM's after service policy?
A: QYM's after service staff will contact you when you received the products, and ask for your comments on the products. Any issues on QYM's products, please send email or call us. QYM will service you timely with whole-heartedness and profession.
Q: What's the MOQ of QYM's product?
A: Different item has different MOQ. Normally 1X20FCL is preferred, LCL could be negotiable.
Q: How can we get the quotation from QYM?
A: Please send your inquiry to QYM's official email.
Q: How to be QYM's agent, wholeseller or distributor in my country?
A: Please send your company's basic information and application to my email adress. A feedback will be sent to you within 7 working days.
Contact Us
- Hebei Qianye Metal Product Co., Ltd
- Contact nameSunny.Su
- Phone86-311-85525702
- AddressGuangan Street Shijiazhuang,Hebei
