FOIF RTS-322R5L TOTAL STATION chinese total station
Specifications
1.FOIF RTS-322R5L TOTAL STATION
2.Reflectorless 200m
3.ship out in 2 working days
FOIF RTS-322R5L TOTAL STATION
Item specifics
Place of Origin:Beijing China (Mainland)
Brand Name:FOIF
Model Number:RTS-322R5L
Color:Green
Windows CE 5.0 operating system
Large full colour graphic display
Guide light system
Multiple interface options
Built-in temperature and pressure sensors
Professional onboard software: FOIF FieldGenius
OTS812 RTS810
Telescope
Length 156mm
Image Erect
Objective aperture 45mm
Magnification 30*
Field of view 1"30'
Shortest focus distance 1.0m
Angle measurement
Reading system Absolute encoder
Angle unit 360"/400gon/mail.selectable
Display resolution 0.5"/1"(or0.1mgon/0.2mgon)
Accuracy 1"/2"/3"/5"
Distance measurement
Single prism 1 to 5000m 1 to 2000m
Three prism / 1to2500m
Accuracy
Reflectoriess 3mm+2ppm /
Measurement time
w 1.5s/0.9s/0.5s 1.5s/0.9s/0.5s
Initial 2.5s 3s
Display resolution (m/inch selectable )
Fine mode 0.1mm/1mm
Temperature Input range -30°C to +60°C
Press input range 510hpa to 1066hpa
Compensator dual axis
Range 3
Level vial sensitivity
Plate level vial 30"/2mm
Circular level vial 8"/2mm
Optical plummet
Accuracy ±0.8mm/1.5m
Image Erect
Magnification 3
Field of view 4"
Focus range 0.5 to ∞
Laser plummet(Factury optional)
Accuracy ±0.8mm/1.5m
Laser class Class2/IEC60825-1
Laser spot size/brightness Adjustable
Laser wave length 635nm
Focus range 0.5 to ∞
Battery
Output voltage 7.4V DC
Continuous Operation time 6 hours (At +20°C)
Charger FDQ7(100v to 240v)
Charging time(at+20°C) Approx.4 hours
On-board software
FOIF Survey .TS or FOIF Field Genius
Application programs
Topography/Data collection/stake out/resection/rem/mlm
AREA/OFF set/point projection/coco/road 3D
Traverse/Tunnel Option only in FOIF Survey TS
Others
Guide light system Factory optional
Sensor Built-in temperature and pressure sensors
Internal memory 1GB standard,extendible(2GB)
Keyboard Alphanumeric keyboard.both sides
Weight(including battery) 6.5KG
Dimensions 210*210*360MM
Operating temperature -20°C to +50°C
Storage temperature -40°C to +70°C
Interface USBhost/USB slave/TS-232C/Bluetooth(optional)
Water and Dust protection IPSS(IEC60529)
