SL62 6x6mm 200x200mm Galvanized Reinforcement Concrete Steel Wire Mesh
Reinforcing mesh is manufactured from ribbed wires,tensile strength of 550 N/mm2, welded mesh welding performance is good. .
Which are welded together with equal spacing in both directions to form square apertures,or different spacing in each direction to form rectangular apertures.
Reinforcing mesh sizes are usually 6.0mx2400mm for the SL and RL productions, can match to the Australia/New Zealand standard AS/N2S 4671:2001.
1. Advantage:
Replaces traditional steel-cutting and fixing on-site
Reduces reliance on site labour and site congestion
Improves buildability and productivity.
2. Applications:
Concrete footpaths
Precast Panel construction
Construction reinforcement
Residential slabs and footings
Industrial and commercial ground slabs
3. Features:
It has a strong and firm body, can bear the high pressure from the concrete and exterior. The reinforcing mesh can save much man-haur, reduce the material cost in the process.
The reinforcing mesh can design by the project requirement, improve the efficiency and bond to the concrete can meet the special construct needs.
It is widely use in airport, tunnel, bridge, highway and wharf, also in the construction of building floor, wall, roof and balcony
Product Description of welded wire mesh
| TYPE | DIA. | MESH | SIZE | WEIGHT | ||
| 4.00MM | 200X200MM | 2.2MX5.8M | 12.6KG | |||
| SL52 | 4.75MM | 200X200MM | 2.2MX5.8M | 16.7KG | ||
| 5.00MM | 200X200MM | 2.2MX5.8M | 19.2KG | |||
| SL62 | 6.00MM | 200X200MM | 2.2MX5.8M | 26.9KG | ||
| SL72 | 6.75MM | 200X200MM | 2.2MX5.8M | 34.2KG | ||
| 7.50MM | 200X200MM | 2.2MX5.8M | 43.1KG | |||
| SL82 | 7.60MM | 200X200MM | 2.2MX5.8M | 43.5KG | ||
| 7.00MM | 200X200MM | 2.2MX5.8M | 35.8KG | |||
| 6.30MM | 200X200MM | 2.2MX5.8M | 29.5KG | |||
| 7.10MM | 200X200MM | 2.2MX5.8M | 38.0KG | |||
| 8.00MM | 200X200MM | 2.2MX5.8M | 48.5KG | |||
| F92 | 8.55MM | 200X200MM | 2.2MX5.8M | 54.9KG | ||
| F102 | 9.50MM | 200X200MM | 2.2MX5.8M | 69.5KG |
