Bluetooth Active Speaker Dedicated Circuit Board Bluetooth Amplifier Module
US$ 13.6 - 14.7
MOQ: 300 Pieces
Key Specifications
Get Latest Price
Brand Name:
sohtronic
Place of Origin:
Christmas Island
Model Number:
SOH-BT202
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
30 days
Related Products
-
Stereo Bluetooth Amplifier ModuleUS$ 3.37 - 3.7MOQ: 500 Pieces -
5V Power Mini Ceiling Speaker Wireless Bluetooth AmplifierUS$ 12.4 - 16.4MOQ: 100 Pieces
-
Bluetooth Amplifier Board Module50W+50WUS$ 13.6 - 14.7MOQ: 500 Pieces
-
T18 Hot Sales Portable Outdoor Bluetooth Stereo 15WUS$ 14.7 - 47.6MOQ: 300 Pieces
-
Tpa31162.1 Channel CSR4.0 Bluetooth AmplifierUS$ 39 - 40.9MOQ: 100 Pieces
Brand Name
sohtronic
Place of Origin
Christmas Island
Model Number
SOH-BT202
Product Description
Product Specification
★Product Name:Bluetooth active speaker dedicated circuit module
★Product Model: CH-BT202/SOH-BT202
★Product Features: With Bluetooth receiving, U disc playing and AUX-in integration, big power, small volume, strong expansibility, reliable performance, high production efficiency, simple assembly process.
★Function Description:
-- 50W stereo CLASS D power amplifier chip, have perfect protection function that over current and overheating ;
-- Bluetooth V2.1 version support A2DP, AVRCP, HFP,SPP;
-- Support FAT16/FAT32 file system MP2/MP3/WMA/FLAC (8/16/24bit) /WAV (IMA-ADPCM and raw PCM) music file playback;
-- Support LED digital display function (Note: need to match CH-305 display PCA module);
-- Traditional knob type potentiometer: volume, bass , treble
-- A group line input, one group line output (line output controlled by volume );
-- Infrared control function;
-- DC15-24V/4-6A input.
★Product Application: active monitors, active Home Furnishing audio, stage speakers, car stereos, outdoor entertainment audio, home KARAOKE audio etc..
★Product size: the maximum element height: ≤28mm
★ double color LED light
1.Red :Long bright for line in mode; play SD/U disk with 0.5S quenching bright flashing, pause at 1S quenching bright flashing; standby is for 1S bright, 3S quenching bright flashing
2. Blue:When bluetooth connects, blue lights flash, connected successfully changed to slow flash;
3. In any mode mute, red and blue light with 0.5S time alternating light;
Important Note:
This module is high precision, high integration of CMOS components, in the production, storage, transportation, installation of various process loop knot, please do the electrostatic protection measures, to prevent electrostatic damage to the device!
The signal amplitude of pre-amplifier output should not be too large, it will make the output distortion grievous , influence the sound!
Pls adopts the cross-sectional area greater than 1 square millimeter copper wire as the power line, switch line and a horn line!
AC impedance of the whole speakers may be low as shunted transmission the loudspeaker, even serial transmission capacitive separated directly. Therefore recommended method of wiring and impedance of reasonable selection of the horn in the use value, which can reduce the power amplifier chip music broadcast signal for large dynamic time overcurrent protection!
All the connection line of interfaces, please ensure that the polarity and the module can be inserted into a consistent, otherwise it will burn the module or the front stage components!
