AluminiumFoilContainerProductionLine
Automatic Aluminium Foil Container Production Line
Model: SEAC-63AS (Three Cavities or Four Cavities Capacity)
Units: Automatic Feeder+Automatic 63Ton Press+Cavities Mould+Auto Stacker+Scrap Sucker& Presser.
It fit for all common size Aluminium Foil Container production requested. The Big capacity could to cover big range of size products. Lower power requested than other old model machines.
Specification:
1.Raw material: Aluminum foil; Thickness: 0.030mm ~0.250mm;
Alloy: 8011,8006,3003,3005; Temper O to H24;
2.Good Japan's Inverter, PLC and 10inch Touch Screen control system;
3.Max. width of Aluminum foil: 800mm;
4.Max. diameter of Aluminum foil: 700mm;
5.Core diameter of Aluminum foil: 76mm(152mm as Optional );
6.Working speed: 40-68 times/min;
7.Total Power: 11.5kw+2kw+2.5kw+3kw;
8.Compressed air needed: 0.5- 0.8 Mpa, 0.3m3/min;
9.Install dimension: 6000*2600*3300mm;
Technical Data:
Max.mould size: 910*900*400mm ;
Slide block stroke: 180-240mm;
Slide block dimension: 360*480mm;
Automatic mould adjust unit: 0.5kw motor;
Work plate dimension: 1200*900mm;
Mould handle hole dimension: 80*80mm(Diameter*Depth);
Power: 4P, 380V or 220V,50Hz /60Hz;
Net weight: 10,500kg.
SE have the Press model: 55Ton, 63Ton, 80Ton,110Ton Common Feeder and Embossing Feeder ,Common Conveyor and Auto Stacker for your option. SEAC-63 is the perfect model to produce food containers. The container's quality accord to the International Environment Protect Standard.
The Embossing Feeder is a nice design, it's a amphibious feeder,it could embossing the foil together feeding;and you can use it only to feeding foil, only need to adjust the emboss unit,so easy !
Auto Stacker will help you upgrade company capacity level and save labour cost !
Price Terms; FOB SHANGHAI
Payment Terms; T/T / L/C
Lead Time; 45-60days
Standards Certificate; CE
Pls Keep Serious Investment Way; Three Cavities Model
