New Design High Pressure Zamak Die Casting Machines

FOB Price

US$ 1,000 - 100,000 / Set

1 Set(Min. Order)

Port xiamen
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China		Brand Name	DELIN zamak die casting machine
Model Number	DL-400 zamak die casting machine		After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

zamak die casting machine:
1. human-computer interface.
2. be applicable to valve, water tag, hardware.

New design high pressure zamak die casting machines :

Introduction:

DL-361 core shooter is a heat core box shooter which is vertically divided, semi-automatic, with the die upturned. Core is taken out manually. The core shooter is applicable to valve, water tag, hardware fittings, hydraulic pressure and small workpieces of variety cores in the air-powered industry.

It is used to produce furan resin series heat core box sand, urea resin series heat core box sand and pre-coated sand core-making.

Characteristics & Applications:

(1)With the human-computer interface, imported high quality electrical and air controlled components, precise and reliable control and convenient operation are guaranteed.

(2) Manually operated with two functions of unicycle and multi-cycle.

(3) The shooting head rotates for 50° to receive sand, it is easy to clean the shooting hole manually.

(5) The machine can be plainly moved as a whole.

(6) Die adjustment margin is set to make it easy to use different dies and lower the requirements of die exterior physical dimension.

Technical data:

model	Automatic core shooting machine
The maximum qualitative properties of the sand core	6Kg
Maximum core box dimension	400×280×200
Heating power	9.6Kw
Productivity	40-100box/hour
Compressed air pressure	0.6Mpa
Die-opening stroke	<300mm
Motor power of the sand hopper	0.25Kw
Conveying speed	72mm/s
Conveying belt angle of rise	2°- 4°
Maximum stroke of the core-pulling guide rod	150 mm
