Home > Transportation > Trailer > Truck Trailer > 2018s High Quality and Competitive Price 3 Axles LHD CLW Brand Electronic Discharging Feed Tank Trailer for Sale

2018s High Quality and Competitive Price 3 Axles LHD CLW Brand Electronic Discharging Feed Tank Trailer for Sale

US$ 30000 - 45000 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

CLW

Place of Origin:

China

Contact Supplier Request Quote Chat Now

Chengli Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai, Qingdao, Guangzhou, Ningbo, Zhangjiagang

Delivery Detail:

20 days

Product Details
Company Profile
Contact Us

Brand Name CLW

Place of Origin China

Triple axles 46cbm bulk feed tank semitrailer, adopts 3 sets of FUWA 13ton bridges, 11.00-20 tyre, 28ton outriggers, 90# /50# traction pin, etc.

The bulk feed tank volume of 46cbm, with the loading capacity of 25tons, adopts high quality 5mm carbon steel, transferring feeds by electronic auger, working with putting on 380volts electronic power. The electronic motor drives the Mechanical auger screw type to discharge with high discharging speed of 0.55ton/min. The Barrel type auger at the tank top is driven by the hydraulic motor, and the electronic bottom control lifting up and down, rotation left and right, with the horizon range of 7.2m and vertical range of 8.2m. So little Residual rate, less than 0.1. And the feed pellet semitrailer can be continuous working, highly improving the working productiveness.

There are 5 compartments of the feed trailer, 5 separate compartments with 5 different kinds of feeds. Every unit is with simple structure, easy and flexible operation, easy to maintenance, etc.

More picutres of hot sale electronic discharging aniaml feed delivery tank trailer manufactured by Chengli Special Automobile Co., Ltd. as below.

High quality and competitive price CLW brand electronic discharging bulk feed tank trailer for sale

main technical parameters of CLW brand electronic discharging feed tank trailer as below

Main technical parameters
Product name	bulk feed trailer(40m3-45m3)
Overall dimension(LWH)	1150025003990
Total mass(kgs)	38100
Wheelbase(mm)	7590+1310+1310
Approach/departure angle	-/14
Front/rear Suspension (mm)	-/2290
Front/rear tread(mm)	-/1840;1840;1840
Leaf spring	-/8/8/8,-/10/10/10
Axle load(kgs)	-/23100(triple axles)
Axle nos.	3
Axles brand	3*13tons FUWA axles
Outriggers	28tons outriggers
Tires specification	11.00-20*12+1
Tractor pin	50#
Toolbox	One set
Spare tire supports	2
Volume	40m3/45m3
Loading capacity	According to the proportion( feed proportion is from 0.4tons/m3 to 0.55tons/m3)
Feed tank material	High quality carbon steel
Compartment	4 separate compartments for 4 different kinds feed
Discharging speed	500-600 kg/min or 1m3/min
Discharging way	Electronic system discharging
Generator unit	Install one set of diesel generator unit to generate electricity
Vertical feeding height	8.5m
Horizontal distance	6.8m
Surplus ratio	﹤0.1

Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of bulk feed truck and animal feed trailer in China. With many year's development, ChengLI Special Automobile Co., Ltd. could offer 8m3 to 40m3 bulk feed delivery trucks and 40m3-50m3 animal feed tank trailer, etc. The animal feed tanks manufactured by Chengli Special Automobile Co., Ltd. are discharging by 380V three-phrase electronic power or hydraulic system. More information, please feel free to contact with Ms. Anita.

Website:

Email: szhj9999@163.com

Mob.: +86 13886878855

Whatsapp/Wechat： +86 13329899995

Skype: truck0011

Product Tags: poultry feed truck , poultry feed tank container , farm-oriented and livestock bulk feed delivery truck
