WRF-1000 High Speed Solvent-free Laminating Machine.
Description:
This machine is high-tech product, which can use dual component (single) solvent-free adhesive for laminating of film, aluminum foil, thin paper and so on. The main parts, such as each transfer roll, coating roll, coating head and wallboard are assembled from high quality manufacturer to ensure the mechanical precision and coating precision of the coating head. The equipment adopts Siemens PLC control system, which has the advantages of high control precision, uniform coating, stable tension and humanization of interface.All electrical and pneumatic parts of the whole machine use high quality original parts to ensure the overall performance of the equipment.
technical parameters：
1. Maximum mechanical speed：300m/min
2. Acceptance laminating speed：250m/min
3. Unwinding coil diameter： Φ600mm
4. Winding coil diameter： Φ800mm
5. Roll paper core：3″
6. Tension range: 3-20 kg 7. Power supply：380V±10%，50Hz，three-phase five-wire.
8. Power of the whole machine：about 25kW(excluding gluing device and mold temperature machine)
9. Compressed air：pressure 0.6Mpa
10. Equipment color：ivory white or designated by the customer
11. External dimensions：5000mm×2400mm×3000mm(L×W×H)
Lamination Material:
1. Max. width range：600mm -1000mm
2. Adaptive materials：
The 1st unwinding：BOPP：20μm-45μm；PET：15μm-40μm；
NYLON：20μm-45μm；Paper: 30-80g/m2；composite film：20-60μm
the 2nd unwinding：PE：30μm-100μm；CPP：25μm-80μm；aluminum foil：8μm-25μm
