OWincor 4915xe passbook printer Technical Specifications:
| Printer type | Multifunction 24-pin flatted printer |
| Printing method | Serial, bidirectional logic-seeking printing |
| Print head | 24 pins, noise-optimized arranement, service life 500 million dots |
| Ribbon |
Fabric ribbon in cartridge, black Service life in DQ: 16million characters |
| Character matrix(horizontal x vertical) |
letter quality LQ24 x 36 Draft quality DQ 24 x 12 Graphic resolution 360 x 180 dpi |
| Printing speed(ar 10 characters per inch, in characters per second) |
DQ 300cps LQ 100cps OCR A/B 145cps DIN letter in DQ 12 seconds DIN letter in LQ 22 seconds |
| Printing width |
10 cpi 90 characters 12 cpi 108 characters 15 cpi 135 characters |
| Character pitch(emulation-dependent) | 10,12,15,16.6,17.1,20 characters per inch and proportional font |
| Line Pitch | 6 and 8 lines per inch, switchable, additional 1/180 inch increments |
| Font | DQ, LQ(Sans Serif, Roman), OCR A/B Barcode 39, 2/5 interleaved |
| Print attributes | Bold, italics, underlined, elongated print, sub-/superscript |
| Character set |
IBM PC2 CP437 in 13 national languages ISO 8859-2/-5/-7/-8/-9 Others available on CD-ROM(PC and Windows code pages) |
| Paper formats |
Single-part forms(mm): Length x width 70-350 70-240 |
| Multiply forms | 1+2 copies |
| Diagnostics functions | Self-test, test printout, hex dump |
| Passbook | Vertical and horizontal fold up to 1.7mm(book thickness when open) |
| Interfaces |
2 x RS232 Centronics USB 2.0(full-speed) |
| Imput buffer | 32 KB |
| Emulations |
Epson ESC/P(ND90, HPR 4904/4905),IBM 4722 and ProPrinter XL24(4009,9068 on request) Olivetti PR40/PR50/PR2 Unisys EFxx |
| Supply voltage |
110-230 volt(self-setting) 50/60 Hz |
| Power consumption | Standby 6 watts/operational 54 watts |
| Environmental conditions(en60721) operational (3k3) |
Temperature: +5°C to 40°C(+41 F to + 104 F) humidity: 5% to 85% |
| Printing noise(EN27779) |
Standby 0dB(A) Operational LQ 55 dB(A)= L |
| Houding color | Light Basic / partially Slate Gray |
| Options |
Magnetic stripe reader, MSR R/W facility for passbooks MICR magnetic stripe reader (CMC7, E13B) |
| Standards compliance | IEC 60950, UL60950, CSA 60950, EN60950, EN55022/B, EN55024, EN60721, EN61000-3-2, EN61000-3-3, class A, FCC CRF47, part 15, subpart B, BSMI Standard CNS 13438 Class B ICES-003(CSA 108.8) |
| Dimensions and weight |
H.: 170mm/6.69 in W.: 380 mm/14.96 in D.: 340 mm/13.39 in W.: |
