Home > Products > Pressure sensor > I2C temperature sensor USB temperature sensor MODBUS temperature sensor
I2C temperature sensor USB temperature sensor MODBUS temperature sensor
- 100 Unit / Units per Month
- sz
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Guangdong, China | Brand Name: | IPS | Model Number: | IT50 |
Usage: | Industrial | Theory: | Thermocouple Thermometer | Accuracy: | 0.1 |
Temperature Range: | -50~2000 |
Product Description
IT50 temperature transmitter uses Pt100 thermal resistor as sensing element. The thermal resistor transforms the measured temperature into electrical signals.It is featured with good performance and stability. It is sealed with epoxy resin, this construction makes it have good ability on anti-shock and withstand high temperature. It also have high mechanical strength , suitable for the application in bad working condition.It has widely been used for temperature measurement in such industries as petroleum industry, chemical industry, spinning and weaving, mine, medicine, electric power, environmental protection, municipal administration, food industry as well as scientific research and so on.
l Applied to the industry, machinery, hydraulic and chemical fields
l Strong anti-pollution capability
l Excellent mechanical strength and insulation performance
l Through the EMC testing, CE certification
l Fast thermal response
l Excellent vibration resistance
Parameters | |||
| Item | Parameter |
|
| Standard Range | Testing range(°C):-50~0;-50~50;0~50;0~80;0~100;0~120;0~150;0~200; |
|
| Installation Mode: Inserting |
| |
| Depth of Inserting (mm): 50mm (typically, beyond the screw threads); custom-made available. |
| |
| Probe Size(mm):Φ6,Φ8 |
| |
| temperature measurement element | PT100 or other thermal resistors |
|
| measured medium | solid, gas or liquid compatible to stainless steel |
|
| measuring range | -200~+500°c |
|
| insert depth | can be made upon customer's request |
|
| output signal | I2C, RS485 |
|
| accuracy | 0.5%FS (standard) |
|
| circuit working temperature range | -40~+85°c |
|
| storage temperature range | -40~+125°c |
|
| temperature | 120% of measured range |
|
| allowed division value /°c | 10~30V DC(15~30V DC for with indicator) |
|
| long term stability | <0.15%FS/year |
|
| response time | <1ms |
|
| process connection | M20x1.5 or others |
|
| material of housing | stainless steel |
|
