Double Glazing Glass Machine 2000
Section of Assembly Pressing Part:
l Italy Technical level of Production ,Installation and Mechanical.
l Japanese Panasonic transducer, Taiwan Wenview monitor, Korean Autonics sensor to keepthe main electric parts running more than 50,000,000 times. All transportation running in automatic ,speed up – press glass --- two or three pieces of glass ordifferent sizes of glass .
l More practical and convenient design of pressing part aboutvacuum , pneumatic driving. It can deal with two or three pieces of glass and curtain walls .
l There is mechanical position &adsorption device system from Taiwan to make it pressing on right position avoid displacement.
l Reasonable hollow glass pressing processto keep all roller got much more longer life also avoid to break any glass.
l It could increase working speed as 45m/min of glass to keep high efficiency (normally 900 pieces in 8 hours by different size insulating glass production).
l The frame is welding by 2.75 mm International Rectangular pipe with high strength structure.
l It is a completely automatic insulating glass production line (can produce LOW-E insulating glass).
l 2-monitor using system-Temperature/Speed/Production volume-Mechanical trouble check-Whole line control function with 1 monitor.
l It realize glass pressing automaticboth outside or inside the press machine. Press glass-normal insulted glass, triple and step insulated glass (selective)and curtain wall glass and abnormity insulated glass.
l Full distance automatic changeable frequency speed adjustment, which can save work waiting time and improve production efficiency.
l Press board can open, easy to examine an repair.
l When insulating glass is pressed, the front and back part of pressing machine will up the glass with lever-type arm and hand system,(mechanical position +mobile sucking system)all this will ensure no malposition.
Section of Cleaning Part:
l Welding by stainless steel with high strength structure ; Top ceiling of it made by 12mm Thickened stainless steel plate, the bottom is made by 5mm thick stainless steel ,the lateral is made by 2mm thick stainless steel.
l There are six High temperature resistant brush with spray washing system to keep all clean process more easier , faster ,thorough and comprehensive.
l All Spare parts in washing box is made by Stainless or Waterproof material to keep all section long and stable working life.
l The Air drying system designed by air circle with naturally aspirated to keep all process more safe and cleaning.(Automatic air system could keep 40℃ of the blowing air).
l It is Key-Link style of gear transmission to keep working in high accuracy.
l Inside part of wash machine, dry machine and the air dryer are both stainless steel production.It is elegant appearance and never rust.
Technical Parameters:
| Input Voltage | 380V 50Hz |
| Total Power | 19.5KW |
| Max Glass Size | 2000×3200mm |
| Min Glass Size | 300×450mm |
| Glass Thickness | 3-19mm |
| Working Speed | 8-48m/min |
| Total Weight | 7500kg |
| Size of Line(L×W×H) | 19000*2350*2680mm |
Butyl Coating Machine
Features
l Automatic control of nozzle width in application of pneumatic and hydraulic parallel method
l Possible to control a precise temperature and 1/100 sec interval of sensor perception
l Easily and quickly changeable of spacer width on a consecutive operation
l Available to select a function for curved spacer, to control and operational height and conveyor belt speed(5 step)
l Easily control able of all functions with Touch Screen and PLC program
l Possible to control the length of Butyl application and monitoring current production quantity on Touch Screen
l Even coating on both sides of the frame
l Continuously adjustable working height
Technical Parameters:
| Input Voltage | 380V 50Hz |
| Total Power | 3.75kw |
| Squeeze Pressure | 10～15Mpa |
| Working Speed | 0～35m/min |
| Temperature | 90～150℃ |
| Adjustable Range | 6～18mm |
| Pistons Diameter | ∮200mm |
| Air Pressure | 0.5～0.8Mpa |
| Outside Dimension | 3000×600×950mm |
