1×2 Optical Switch
Features
l Low Insertion Loss
l Wide Wavelength Range
l Low Crosstalk
l High Stability, High Reliability
l Epoxy-free on Optical Path
l Latching and Non-latching
Application
l Metropolitan Area Network
l R&D in Laboratory
l System Monitoring
l Configurable OADM
Performance
Parameters |
OSW-1×2 |
||
Wavelength Range |
nm |
650~1310 |
1260~1670 |
Testing Wavelength |
nm |
650/780/850/980/1064/1310 |
1310/1490/1550/1625/1650 |
Insertion Loss |
dB |
Typ:0.6,Max:1.0 |
Typ:0.5 ,Max:0.8 |
Return Loss |
dB |
≥30 |
≥50 |
Crosstalk |
dB |
≥35 |
≥55 |
PDL |
dB |
≤0.05 |
|
WDL |
dB |
≤0.25 |
|
TDL |
dB |
≤0.25 |
|
Repeatability |
dB |
≤±0.02 |
|
Power supply |
v |
3.0 or 5.0 |
|
Lifetime |
Cycle |
≥107 |
|
Switch Time |
ms |
≤8 |
|
Transmission Power |
mW |
≤500 |
|
Operation Temperature |
℃ |
-40~+85 |
|
Storage Temperature |
℃ |
-40~+85 |
|
Weight |
g |
16 |
|
Dimension |
mm |
(L)27×(W)12.6×(H)8.5(±0.2) |
|
Route States
Pins
Optical Path |
Electric Drive |
Sensor Status |
|||||
1×2 |
1 |
5 |
6 |
10 |
3－4,7－8 |
2－3,8－9 |
|
Latching |
P1---P2 |
N/A |
N/A |
GND |
+5V |
OPEN |
CLOSE |
P1---P3 |
+5V |
GND |
N/A |
N/A |
CLOSE |
OPEN |
|
|
Non- Latching |
P1---P2 |
N/A |
N/A |
N/A |
N/A |
OPEN |
CLOSE |
P1---P3 |
+5V |
N/A |
N/A |
GND |
CLOSE |
OPEN |
|
Electrical parameters
Voltage |
current |
Resistor |
|
5V Latching |
4.5~5.5 |
36~44mA |
125Ω |
5V Non-Latching |
4.5~5.5 |
26~32mA |
175Ω |
3V Latching |
2.7~3.3 |
54~66mA |
50Ω |
3V Non-Latching |
2.7~3.3 |
39~47mA |
70Ω |
Dimensions
Ordering Information：OSW－1×2－A－B－C－D－E－F－G
A |
B |
C |
D |
E |
F |
G |
Mode |
Wavelength |
Voltage |
Control Model |
Fiber Diameter |
Fiber Length |
Connector |
|
SM:9/125um M5: 50/125um M6: 62.5/125um |
85: 850nm 13: 1310nm 14: 1490nm 15: 1550nm 162: 1625nm 165: 1650nm 13/15:1310/1550nm |
3: 3V 5: 5V |
L: Latching N:Non-Latching |
25:250um 90:900um 20:2.0mm 30: 3.0mm |
05:0.5m 10:1.0m 15:1.5m |
OO:None FP: FC/PC FA: FC/APC SP: SC/PC SA: SC/APC LP: LC/PC LA: LC/APC |
