Wholesale Ultra-large Rock Splitters
- 1000 Set / Sets per Month
- shanghai
- T/T L/C
- 30 days
Product Details
Brand Name: | ZHONGTUO | Place of Origin: | China | Certification: | SGS |
After-sales Service Provided: | Engineers available to service machinery overseas | Warranty: | 1 year | Application: | Rock excavation |
Motor Type: | AC Motor |
Product Description
Ultra-large Rock Splitters
Advantages of ultra-large rock splitters:
Economical - Blasting usually requires work stoppages and the installation of protective walls and other safety equipment. This costs both time and money. With high-performance rock and concrete splitters, blasting is not longer necessary. Therefor, there is no potential danger to the workforce or passers-by, and other work in the immediate surroundings can continue unaffected.
Safe - Hydraulic splitting means controlled demolition. The entire force developed is always under full control. There is no danger of flying debris, vibrations or even explosions.
Environmental-friendly When using the hydraulic splitting technique, there are unpleasant side effects like vibrations and dust. Even noise emission is extremely low, which means that, all in all, this demolition technique is particularly environmental-friendly. That is why the splitter is indispensable in densely populated areas or inside buildings.
Durable - Thanks to the extremely robust design, the rock and concrete splitter can withstand even the toughest conditions. Its durability is quite exceptional. Therefore, next to no maintenance is required. Yet another cost-saving factor.
Autonomy - splitters and pump units are easy to transport. Operators no longer depend on heavy machinery, e.g. Excavators, for their transport to the demolition site. Therefore, even the smallest workplace is no longer a problem.
Easy to use - The splitters are extremely easy to operate. The lightweight design enables and operator to work on a splitting job single-handedly. Even unskilled worker can learn to use the splitter in a very short time.
Down the hole Drill rigs machines are also necessary for rock/block splitting.
Product parameters of ultra wedge rock splitter:
Technical parameters of ultra wedge rock splitter | |||||||
model | Split block length mm | drilling depth m | nominl workig pressure MPa | disruptive forceT | crack width | Opposite hole form
| Machine weight KG |
ZT220-P90 | 800-900 | 1300mm | 24-25 | 3300- 3600 | 25- 30 | The chain of manual hole | 600 |
ZT260-P100 | 950-1000 | 1700mm | 24-25 | 4400- 5200 | 30-25 | The chain of manual hole | 650 |
ZTN50-P100 | 1000-1200 | 2100mm | 24-25 | 6000 | 30-25 | The chain of manual hole | 730 |
Application of Ultra Large Rock Splitter:
Ultra Large Rock Splitter is mainly used for: primary and secondary disintegration of large ore (metal ore, nonmetallic ore), rock dissolution of rock, rock mining of quarry, local and all demolition operations of large concrete Compared with the traditional operation mode in the above field, the airborne splitting machine has a series of advantages such as huge splitting force, simple structure, convenient operation, high operation efficiency, low cost, safety and energy saving.
