| Australian electricity standard CE certification approved large power 650kva diesel generator unit | |
| Generator set specifications | |
| Governor Class | ISO8528 G3 |
| Potential Drop | ±1% |
| Steady Voltage Regulation | ±1% |
| Frequency Drop | Synchronous(0%) |
| Steady-state Frequency | ±0.25% |
| R.R.I.Suppression | BS EN 61000-6-4 / BS EN 61000-6-2 |
| Fuel Consumption Rate ,g/kw.h(L/hr) | 207 (125.16) |
| Starting Battery Capacity ,A/hrhhr | 200*2 |
| Total Coolant Capacity ,L | 116.5 |
| Fuel Capacity (base tank),L | N/A |
| Engine Data | |
| Model | KTAA19-G6 |
| Type | In-line 6 Cylinder,4 Cycle |
| Displacement ,L | 18.9 |
| Compression Ration | 13.5:1 |
| Aspiration | Turbo, Air / Air Cooling |
| Fuel System | PT type Fuel Pump,EFC Electronic Governor |
| Bore*Stroke(mm) | 159*159 |
| Rated Speed ,rpm | 1500 |
| Governor Type | Electronic |
| Starting Voltage | 24V ,Negative ground |
| Battery Charging System | 24V 35A |
| Lubricant Capacity ,L | 50 |
| Coolant Capacity, L | 116.5 |
| Alternator Data | |
| Protection Class | IP21 |
| Insulation Class | Class H |
| Temperature Rise in Standard | 125 ℃(When Ambient Temp.is 40 ℃) |
| Excitation Type | Brushless & Self-excited |
| Waveform Distortion | No load |
| Telephone Interference(TIF) | |
| Telephone Interference(THF) | |
| Exhaust System | |
| Exhaust air flow | 1992 L/S |
| Exhaust Temperature | 190℃ |
| Max Back Pressure | 10kPa |
| Air Intake System | |
| Max Intake Restriction | 6.23 kPa |
| Burning Capacity | 750 L/S |
| Air Flow | 10800 L/S |
| Lubricant System | |
| Total Lubricant Capacity | 50L |
| Lubricant Consumption | ≤4g/kwh |
| Engine Oil Tank Capacity | 38L |
| Oil Pressure at Rated Speed | 345-483 kPa |
| Cooling System | |
| Total Coolant Capacity | 116.5L |
| Thermostat | 82-93℃ |
| Max Water Temperature | 104℃ |
| Model No. | STANDBY POWER | PRIME POWER | ENGINE | ALTERNATOR | CONTROLLER | ||
| KVA | KW | KVA | KW | ||||
| OCL-650 | 650 | 520 | 575 | 460 | KTAA19-G6 | LTG354FA1 | 6110 |
Standard Feature:
1.This series diesel generator set which adopt with Cummins engine has characteristics:sight volume, large power and low noise.
2.Integration module structure design, which makes the total amount of spare parts 25% less than other brand.
3.Good smooth running performance.
4.The generator/altemator matches domestic famous brand brushless LEADTECH, also can select it according to customer request.
5.Auto-regulate voltage,auto stop when high water temperature, low oil voltage and over speed rotating Remote & monitoring by 485 connections.
Optional Feature:
1.Sound and water proof enclosure
2.Trailer!//Movable power station
3.Secondary silencer
4.Battery charger
5.Water jacket heater
6.Oil heater
7.Diesel oil heater
8.Electric speed controller
9.Automatic transfer switches(ATS)
10.Extra fuel tank
(Not all features and options listed.)
1.Q: What is your MOQ of this item?
A:1 set
2.Q: What is the lead time?
A:10 working days after received the 30%T/T deposit
3.Q: Is it all right to make customer's own brand name?
A:We can be your OEM manufacture with your authorization of brand.
4.Q: Where is your Loading Port?
A:Foshan,Guangzhou or Shenzhen
5.Q: What are your payment terms?
A:30% TT as deposit,70% TT before Shipment.
6.Q: What is your company's available production capacity?
A:200 Set/Sets per Month
7.Q:What's the power range of diesel generators?
A:Power range from 5kva~3000kva.
