Silent Type Hydraulic Impact Breaking Hammer
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
UT
Place of Origin:
China
Model Number:
Customized
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao, Shanghai, Ningbo
Delivery Detail:
10 days
Related Products
-
Excavator Attachments Hydrualic Quick HitchUS$ 666 - 3999MOQ: 1 Piece -
Excavator Attachments Hydrualic Quick CouplerUS$ 666 - 3999MOQ: 1 Piece
-
Machinery Parts Excavator Hydrualic Quick CouplerUS$ 666 - 3999MOQ: 1 Piece
-
Machinery Parts Excavator Hydrualic Quick HitchUS$ 666 - 3999MOQ: 1 Piece
-
Excavator Quick Hitch CouplerUS$ 666 - 3999MOQ: 1 Piece
Brand Name
UT
Place of Origin
China
Model Number
Customized
Excavator Hydraulic Impact Hammer
Types of Hydraulic Breaker
| Types | Model |
| Boxed Type |
Light Series UTHB-B45-100 |
| Medium Series UTHB-B125-155 | |
| Heavy Duty Series UTHB-B167-175 | |
| Top Type |
Light Series UTHB-B45-100 |
| Medium Series UTHB-B125-155 | |
| Heavy Duty Series UTHB-B165-210 | |
| Side Type |
Light Series UTHB-B45-100 |
| Medium Series UTHB-B125-155 | |
| Heavy Duty Series UTHB-B165-210 |
Features:
1.Strong impact
2.Simple structure
3.Refining technology
Boxed Type - Light Series 45-100
UTHB-B-45
| Cylinder Weight | 62 | kg |
| Total Weight | 128 | kg |
| Overall Length | 1279 | mm |
| Required Oil Flow | 20-40 | L/min |
| Working Pressure | 90-120 | Kg/cm2 |
| Impact Rate | 700-1200 | b.p.m |
| Chisel Diameter | D45 | mm |
| Application Excavator | 0.8-1.5 | ton |
UTHB-B-53
| Cylinder Weight | 80 | kg |
| Total Weight | 170 | kg |
| Overall Length | 1446 | mm |
| Required Oil Flow | 20-50 | L/min |
| Working Pressure | 90-120 | Kg/cm2 |
| Impact Rate | 600-1100 | b.p.m |
| Chisel Diameter | D53 | mm |
| Application Excavator | 2.5-4.5 | ton |
UTHB-B-70
| Cylinder Weight | 146 | kg |
| Total Weight | 343 | kg |
| Overall Length | 1652 | mm |
| Required Oil Flow | 40-70 | L/min |
| Working Pressure | 110-140 | Kg/cm2 |
| Impact Rate | 500-900 | b.p.m |
| Chisel Diameter | D70 | mm |
| Application Excavator | 4-7 | ton |
UTHB-B-75
| Cylinder Weight | 207 | kg |
| Total Weight | 477 | kg |
| Overall Length | 1862 | mm |
| Required Oil Flow | 50-90 | L/min |
| Working Pressure | 120-150 | Kg/cm2 |
| Impact Rate | 400-800 | b.p.m |
| Chisel Diameter | D75 | mm |
| Application Excavator | 6-9 | ton |
UTHB-B-85
| Cylinder Weight | 263 | kg |
| Total Weight | 658 | kg |
| Overall Length | 2140 | mm |
| Required Oil Flow | 60-100 | L/min |
| Working Pressure | 130-160 | Kg/cm2 |
| Impact Rate | 400-800 | b.p.m |
| Chisel Diameter | D85 | mm |
| Application Excavator | 7-14 | ton |
UTHB-B-100
| Cylinder Weight | 444 | kg |
| Total Weight | 935 | kg |
| Overall Length | 2310 | mm |
| Required Oil Flow | 80-110 | L/min |
| Working Pressure | 150-170 | Kg/cm2 |
| Impact Rate | 350-700 | b.p.m |
| Chisel Diameter | D100 | mm |
| Application Excavator | 11-16 | ton |
Box Type-Medium Series 125-155
UTHB-B-125
| Cylinder Weight | 562 | kg |
| Total Weight | 1422 | kg |
| Overall Length | 2609 | mm |
| Required Oil Flow | 90-120 | L/min |
| Working Pressure | 150-170 | Kg/cm2 |
| Impact Rate | 350-650 | b.p.m |
| Chisel Diameter | D125 | mm |
| Application Excavator | 15-18 | ton |
UTHB-B-135
| Cylinder Weight | 713 | kg |
| Total Weight | 1669 | kg |
| Overall Length | 2706 | mm |
| Required Oil Flow | 120-180 | L/min |
| Working Pressure | 160-180 | Kg/cm2 |
| Impact Rate | 350-500 | b.p.m |
| Chisel Diameter | D135 | mm |
| Application Excavator | 18-21 | ton |
UTHB-B-140
| Cylinder Weight | 793 | kg |
| Total Weight | 1849 | kg |
| Overall Length | 2786 | mm |
| Required Oil Flow | 120-180 | L/min |
| Working Pressure | 160-180 | Kg/cm2 |
| Impact Rate | 350-500 | b.p.m |
| Chisel Diameter | D140 | mm |
| Application Excavator | 18-26 | ton |
UTHB-B-150
| Cylinder Weight | 954 | kg |
| Total Weight | 2313 | kg |
| Overall Length | 1765 | mm |
| Required Oil Flow | 150-210 | L/min |
| Working Pressure | 160-180 | Kg/cm2 |
| Impact Rate | 300-450 | b.p.m |
| Chisel Diameter | D150 | mm |
| Application Excavator | 25-30 | ton |
UTHB-B-155
| Cylinder Weight | 1102 | kg |
| Total Weight | 2643 | kg |
| Overall Length | 3161 | mm |
| Required Oil Flow | 180-240 | L/min |
| Working Pressure | 160-180 | Kg/cm2 |
| Impact Rate | 300-450 | b.p.m |
| Chisel Diameter | D155 | mm |
| Application Excavator | 28-35 | ton |
