I-pulse p053 nozzle

I-pulse P005/P006/P012/P013/P017/P018/P019/P020/P031/P032/P033/P034/P042/P053 NOZZLE for M6 Placement machine

I-pulse series nozzles:
1.M1/M4 type:M001/M002/M003/M004/M005/M006/M012/M013/M017/M018/M019/M020/M021/M022/M031/M032/M033
2.M2 type:N001/N002/N003/N004/N005/N006/N012/N013/N017/N018/N019/N020/N021/N022/N031/N032/N033
3.M6 type:P005/P006/P012/P013/P017/P018/P019/P020/P031/P032/P033/P034/P042/P053
4.FV7100/5530 type: K01/K02/K03/K04/K05/K06/K018/K019/K020
5.MT5800 type:G01/G02/G03/G04/G05/G06/G07/G08/G09/G10/G71
6.MT5620E/5520E type:1005/1608/2125/3216

 M1 & M4 (M Series Nozzles) Description:
 M001   LG0-M7701-00X   I-PULSE M1 SERIES PK NZ -M001 (0.5 X 0.4)**
 M002   LG0-M7703-00X   I-PULSE M1 SERIES PK NZ -M002 (0.9 X 0.62)
 M003   LG0-M7705-00X   I-PULSE M1 SERIES PK NZ -M003 (1.3 X 0.7)
 M004   LG0-M7707-00X   I-PULSE M1 SERIES PK NZ -M004 (1.8 X 1.2)
 M005   LG0-M7709-00X   I-PULSE M1 SERIES PK NZ -M005 (3.0 X 2.0)
 M006   LG0-M770B-00X   I-PULSE M006 NOZZLE   OD : 4.5 / ID : 3.5 **
 M012   LG0-M770E-00X   I-PULSE M012 NOZZLE   OD : 2.0 / ID : 0.8 **
 M013   LG0-M770G-00X   I-PULSE M013 NOZZLE  OD: 2.5 / ID : 1.2 **
 M017   LG0-M770H-00X   I-PULSE M1 SERIES PK NZ -M017 (3.6 X 0.6)(W/RUBBER PAD)
 M018   LG0-M770K-00X   I-PULSE M1 SERIES PK NZ -M018 (6.0 X 1.2)(W/RUBBER PAD)
 M019   LG0-M770K-00X   I-PULSE M1 SERIES PK NZ -M019 (8.0 X 1.2)(W/RUBBER PAD)
 M020   LG0-M770P-00X   I-PULSE M020 NOZZLE (W/RUBBER PAD) **


M2 (N Series Nozzles) Description:
 M001   I-PULSE M2 SERIES PK NZ -N001 (0.5 X 0.4)**
 N002   I-PULSE M2 SERIES PK NZ -N002 (0.9 X 0.62)
 N003   I-PULSE M2 SERIES PK NZ -N003 (1.3 X 0.7)
 N004   I-PULSE M2 SERIES PK NZ -N004 (1.8 X 1.2)
 N005   I-PULSE M2 SERIES PK NZ -N005 (3.0 X 2.0)
 N006   I-PULSE N006 NOZZLE   OD : 4.5 / ID : 3.5 **
 N012   I-PULSE N012 NOZZLE   OD : 2.0 / ID : 0.8 **
 N013   I-PULSE N013 NOZZLE  OD: 2.5 / ID : 1.2 **
 N017   I-PULSE M2 SERIES PK NZ -N017 (3.6 X 0.6)(W/RUBBER PAD)
 N018   I-PULSE M2 SERIES PK NZ -N018 (6.0 X 1.2)(W/RUBBER PAD)
 N019   I-PULSE M2 SERIES PK NZ -N019 (8.0 X 1.2)(W/RUBBER PAD)
 N020   I-PULSE M020 NOZZLE (W/RUBBER PAD) **

M7, M8 Nozzles (P Series Nozzles) Description:
Model              Part Number                Description
P001           LC6-M7701-001                  P001 0.5x0.4
P002           LC6-M7703-001                  P002 0.9x0.6
P003           LC6-M7705-001                  P003 ø1.3/ø0.65
P004           LC6-M7707-001                  P004 ø1.8/ø1.2
P005           LC6-M7709-001                  P005 ø3.0/ø2.0
P006           LC6-M770B-001                  P006 ø4.5/ø3.5
P012           LC6-M770D-001                  P012 ø2.0 Melf
P013           LC6-M770F-001                  P013 ø2.5 Melf
P017           LC6-M770H-001                  P017 ø4.0 Rubber
P018           LC6-M770K-001                  P018 ø6.0 Rubber
P019           LC6-M770M-001                  P019 ø8.0 Rubber
P020           LC6-M770P-001                  P020 ø10.0 Rubber

P/N: LG0-M7703-00     Des: Nozzle,M002 0.95mmx0.65mm
P/N: LG0-M7703-00XS Des: Nozzle,M002 (modified) 0.7/0.45
P/N: LG0-M7705-00     Des: Nozzle,M003 1.3/0.65
P/N: LG0-M7707-00     Des: Nozzle,M004 1.8/1.2
P/N: LG0-M7709-00     Des: Nozzle,M005 3.0/2.0
P/N: LG0-M770B-00    Des: Nozzle,M006 4.5/3.5
P/N: LG0-M770D-00    Des: Nozzle,M012 2.0/0.9
P/N: LG0-M770F-00    Des: Nozzle,M013 2.5/1.2
P/N: LG0-M770K-00    Des: Nozzle,M018 6.0 PAD
P/N: LG0-M771K-00    Des: Nozzle,M032 BUFFER NOZZLE
P/N: Des: Nozzle,M001 0.4mmx0.5mm
P/N: Des: Nozzle,M017 4.0 PAD
P/N: Des: Nozzle,M019 8.0 PAD
P/N: Des: Nozzle,M020 10 PAD Machine i-Pulse M2
P/N: LC1-M7701-00   Des: Nozzle,N001
P/N: LC1-M7703-00 Des: Nozzle,N002 0.95mmx0.65mm
P/N: LC1-M7703-00XS Des: Nozzle,N002 (modified) 0.7/0.45
P/N: LC1-M7705-00 Des: Nozzle,N003 1.3/0.65
P/N: LC1-M7707-00 Des: Nozzle,N004 1.8/1.2
P/N: LC1-M7709-00 Des: Nozzle,N005 3.0/2.0
P/N: LC1-M770B-00 Des: Nozzle,N006 4.5/3.5
P/N: LC1-M770D-00 Des: Nozzle,N012 Melf
P/N: LC1-M770F-00 Des: Nozzle,N013 Melf
P/N: LC1-M770H-00 Des: Nozzle,N017 4 PAD
P/N: LC1-M770K-00 Des: Nozzle,N018 6 PAD
P/N: LC1-M770M-00 Des: Nozzle,N019 8 PAD
P/N: LC1-M770P-00 Des: Nozzle,N020 10 PAD
P/N: LC1-M770S-00 Des: Nozzle,N021
P/N: LC1-M770U-00 Des: Nozzle,N022
P/N: LC1-M7714-00 Des: Nozzle,N032 BUFFER NOZZLE
