DETAILED PRODUCT DESCRIPTION
The PGT300AC door opener designed for tilting up and over garage door use, up to 10 sq.m..
Built in control unit with 433.92 MHz receiver
Built in LED courtesy light
Keypad / single button interface.
Alarm lamp, Photo beam & safety beam interface.
Mechanical limit switch
Manual key release design for emergency purposes.
Installation accessories with pull rod and bush.
Available for two door openers mounted on each side for larger door.
Main technical parameters
Unit Model |
PGT300AC |
Power supply |
220V/110V |
Motor power |
200W |
Output torque |
350N·m |
Door max surface |
9Sq.m. |
Work duty |
S2, 15min. |
Limit switch |
Mechanical limit switch |
Gate move speed |
20cm/sec |
Remote control range |
≥30 m |
Extra remote control |
25 (2 included) |
Frequency |
433.92mHz) |
Noise |
≤58dB |
Working temperature |
-20°C~+70°C |
Weight |
14 kg |
