Down Blanket Making Machine

Down Blanket Making Machine photo-1
US$ 19,999 - 49,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Textiles
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
ShangHai QingDao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Apparel, Textiles
Packaging Type Cartons
Packaging Material Wood
Automatic Grade Automatic
Driven Type Pneumatic
Voltage 220V
Power 3.5KW
Place of Origin Shandong, China
Brand Name Bealead
Model Number 618B
Dimension(L*W*H) 2300*2200*2000mm
Weight 600KG
Certification CE certification
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Down Blanket Making Machine
High efficiency & accuracy
Labor cost saving
Accurate weighing module
Widely usage

Down Blanket Making Machine



Item no.

618B

Dimension

2300*2200*2000mm

Weighing Ability

0.3-32g

Accuracy

+/-3%

Air pressure

0.8~1.0Mpa

Power

3.5kw

Voltage

220V 50Hz

Material Application

Duck Down 50 Up

Filling Speed

1g/s~8g/s(adjustable)

Efficiency

2-3times faster than Hand filling

Features:

1. High accuracy weighing module can measure accurately with tolerance less than 0.2g per filling time.



2. Dual Recycle Weighing System, Each filling nozzle have two sets of weighing devices, saving weighing time, substantially improve efficiency, and save labor cost as well.



3. Vacuum filling system, suitable for different materials of grids, non-airing materials can be used



4. Filling nozzles with special design avoid the down flying and scatted everywhere.



5. Parameter save function in the program, the data of different grids can keep and number by program for later using.





Min. air compressure of pump: 1.0m³ /min Up



Power of air pump: 7.5kw up



Recommend high pressure pneumatic pump 1.0 Mpa



Air tank: 0.6 m³  Up, prolong a life of air compressor



Machine covering space: 2.3m*2.2m



Min. floor space of machine: 4m*5m



Any questions, pls contact us freely.



Down Blanket Making Machine



Down Blanket Making Machine



Down Blanket Making Machine



Down Blanket Making Machine
