Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > Large-Format Digital UV Roll to Roll Printer RUV-3204
Large-Format Digital UV Roll to Roll Printer RUV-3204
US$ 10000 - 20000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
SinoColor
Place of Origin:
China
Model Number:
RUV-3204
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
10 days
Related Products
-
Large-Format UV Flatbed Printer FB-0906 (90x60cm) FB-1313 (130x130cm) FB-2513 (250x130cm)US$ 6500 - 15000MOQ: 1 Set -
Super Fast Solvent Printer Speedy Monster KM-512iUS$ 10000 - 20000MOQ: 1 Set
-
Direct Flag Printer FP-740 ProUS$ 6000 - 15000MOQ: 1 Set
-
Eco Solvent Printer 74-inch / 1.8 Meter Flagship Model Storm SJ-740NegotiableMOQ: 1 Set
-
A2 Large Format Drawing Cabinet|594*297mm| With Roller-Type Drawers & Steel Lock System – Ideal for Architecture Firms and Design StudiosUS$ 70 - 1300MOQ: 5 Combos
Brand Name
SinoColor
Place of Origin
China
Model Number
RUV-3204
Certification
ce
After-sales Service Provided
Engineers available to service machinery overseas
Weight
1000kg
Voltage
110/220 v
Usage
Label Printer, Paper Printer, Tube Printer
Condition
New
Automatic Grade
Semi-Automatic
Gross Power
3000 w
Color & Page
Single Color
Plate Type
Other, Roll to Roll
OverviewWith the RUV-3204, you can easily create vibrant prototypes and short runs on a variety of actual press substrates, in one seamless workflow. Decor wallpaper, Ad banners, Flexible bag media, Labels. Clear film. CMYK, White, Varnish, Emboss, Crease. All with a single device.
VISIT WEB : TO GET MORE INFOMATION
Layered / Emboss EffectThis has the impressive affect of highlighting and drawing attention to that part of the design. Not only that, the varnish coating adds shining effect to the prints.
Industrial-grade Rocoh GEN5 PrintheadTo ensure rich, consistent color at high speed and high resolution, the RUV-3204 features the latest industrial level Ricoh printhead that delivers rich, vibrant, consistent colors during bi-directional printing. It is designed with longevity and robustness in mind and widely used in many latest industrial inkjet printers.
CMYK + W + Clear Coat Ink (Varnish)The RUV-3204 prints flawless graphics and text with vibrant UV inks including CMYK, White and Clear Coat for remarkable special effects ranging from gloss or matte finishes to custom textures and simulated embossing.
8 Level Gray PrintingWith the new 8-level gray technology, the color contrast parameter now has a much wider range, and the prints look even more vivid than ever.
Energy-saving UV-LED light curving systemThe RUV-3204 is equipped with the high quality UV-LED with all advanced features, long lifespan, low heat, instant on-off.
Advanced Media HandlingWith SinoColor advanced movement control system, chromatic banding is virtually eliminated, each pass is uniform allowing for more sellable output in less time.
Ink Alarm SystemThe bulk and waste ink tank are installed with level sensors to alarm ink refill and overflow signal.
1280 NozzlesEach printhead has 1280 nozzles which is far more than that of Epson printhead, thus the print speed and color consistance are greatly increased.
Negative Pressure Ink Supply SystemThe negative pressure ink system ensures high stability of ink supply. Operator can easily monitor the system and control negative pressure. The system adjusts the ink pressure automatically, no manually operation is needed. Air pump works only when the air pressure is needed, offers stable air pressure.
Integrated Tri-Heater SystemThe SinoColor RUV-3204 integrate the tri-heater system, so that the media becomes more uniform and the ink drys faster. Moreover, the heat controllers have been integrated in one panel to simplify user operation.
Gallery
Application
Specification
| Model No. | RUV-3204 | ||
| Printhead | Industrial piezoelectric heads (3/4 heads, tows) | ||
| Printing Resolution | 300dpi 600dpi 900dpi 1200dpi | ||
| Drop Size | MIN 7pl | ||
| Printing Width | 210 to 3200mm | ||
| Meida | Width | 210 to 3250mm | |
| Thickness | MAX 1mm(0.039in) | ||
| Speed | High Quality | 8 Pass, 22 sqm/h | |
| Standard | 6 Pass, 30 sqm/h | ||
| Draft | 4 Pass, 44 sqm/h | ||
| Ink | Type | LED UV | |
| Color | C M Y K / C M Y K + 1W/2W | ||
| Volume | 5L Ink Bottle | ||
| Drying Method | Double UV LED Light | ||
| Connector | USB 2.0 | ||
| Power Requirement | AC 110V /220V ± 5%, 16A, 50Hz ± 1 | ||
| Power Comsuption | MAX 3000W | ||
| Weight(with holders) | 1000KG | ||
