security equipment reed switch normally closed magnetic reed switch
Mobile phone: +86-13008800940
OEM/ODM solid factory in Shenzhen city China, for your special customized Magnetic Sensor Proximity Switch project.
Less worry, more profit. Start from here.
Magnetic Reed Switch Sensor is widely used in Household Appliance, Communication Electronics, Automobile, Medical Care, Security Electronics, Industrial field and daily life.
Every day you probably use Magnetic Reed Switch Sensor without notice, (such as when using the Washing machine, opening Laptop, entering doors, getting milks from fridge etc )
You will not like to leave it alone once you realize its existing and powerful functions.
Magnetic Reed Switch Sensor consists of core compenent ---- the Reed Switch, and the cable, and finally its clothes housing case.
Reed Switch is a magnetic special switch, is the main component of the reed relay and proximity switch. The reed switch was invented by Walter B. Ellwood of Bell Telephone Lab
in 1936, who was patented in the United States on June 27, 1940, patent number 2264746.
ShenZhen CiAn Electronics Co.,LTD specializes in the R&D, production and service of Magnetic Reed Switch Sensor. With modern production lines and device, workers and
managerment, ShenZhen CiAn Electronics Co.,LTD has owned good reputation both at home and abroad. We export to many countries in the world with long term cooperation
relationship for the aim of providing standard and customized solutions for all kinds of applications. Please contact us if you are looking for professional factory of Magnetic Reed Switch Sensor.
CE and Rohs Compliant. UL available.
All specification can be customized:
Core component: Proximity swtich magnetic sensor without function of pressure/inductive/transducer sensor
* Reed Switch OKI / MKA / HAMLIN
* Total Length mm (Default or Customized)
* Glass Length mm (Default or Customized)
* Glass Diameter mm (Default or Customized)
* Contact Form 1A (SPST-NO) (Default or Customized)
* Contact Position SYM (Default or Customized)
* Contact Material Ru (Default or Customized)
* Contact Rating 10W (Default or Customized)
* Max. Switching Voltage VDC / VAC (Default or Customized)
* Max. Switching Current (Default or Customized)
* Contact Resistance (at initial value) (Default or Customized)
* Pull In Value (AT) 10-15 (Default or Customized)
* Drop Out Value (AT) 5 (Default or Customized)
* Operation Time 1.0 mSec.(Max.) (Default or Customized)
* Release Time 0.4 mSec.(Max.) (Default or Customized)
* Breakdown Voltage 220VDC(AT25) (Default or Customized)
* Contact Capacitance 0.7 pF (Default or Customized)
* Insulation Resistance 1010Ohms (Default or Customized)
* Resonant Frequency 4 kHz (Default or Customized)
* Operation Temperature -60 ºC ~+155 ºC (Default or Customized)
* High Humidity 98% (Max.) (Default or Customized)
* Operation Frequency 100 Hz (Default or Customized)
* Electrical Life 108(5V ,10mA) 105(24V, 400mA) (Default or Customized)
* Test Coil 5000 870 Ohm (Default or Customized)
* Leads Gold-Plated (Default or Customized)
Housing case:
* Materials: ABS, Zinc/Aluminum, Compo etc (Default or Customized)
* Design: Our current models or new design model. (Default or Customized)
* Structure: Cylinder, Cuboid, Groove, SMD, (Default or Customized)
* Color: White, Black (Default or Customized)
Wire:
* UL 24# (Default or Customized)
* Color: White (Default or Customized)
Please contact us now for more details. Faster response with professional solution ensures success.
