Help CenterUHMW PE Pipe to Convey Foodstuff
Related Products
-
Sand and Stones,cement,lime,fire-resistance Material,concrete Transportation by UHMW PE PipeUS$ 6 - 88MOQ: 300 Meters -
UHMW PE Pipe to Convey Pulp and Metallurgical Waste ResidueUS$ 6 - 88MOQ: 300 Meters
-
UHMW PE Pipe to Convey Mortar in Thermoelectricity FieldUS$ 6 - 88MOQ: 300 Meters
-
UHMW PE Pipe to Replace Teel Pipe to Convey Crude Oil and Sewage in Petroleum FieldUS$ 6 - 88MOQ: 300 Meters
-
UHMW PE Pipe in Coal-mineral IndustriesUS$ 6 - 88MOQ: 300 Meters
UHMW PE PIPE: Guorun uhmwpe pipe with more than 2 million molecular weight is a new development and replacement of pe & hdpe pipes. Guorun uhmwpe pipes’s main characteristics are as follows: 1.Extremely high wear resistance; Its wear resistance is 6.6 times higher than normal alloy steel, 27.3 times that of stainless steel, 4-7 times 17.9 times that of phenolic resin,6. 4 times that of polyethylene 2.High impact resistance: It won’t damage by Cantilever beam impact test according to GB1843 standards 3.High corrosion resistance: It can withstand hydrochloric acid with less than 80% concentration 4.High-pressuer resistance: The working pressure is between 0.2Mpa to 4.0Mpa 5.Good self-lubrication: Its self-lubrication is better than steel or brass with oil 6.The unique resistance to low temperature:It can be used within -269 to 80 degrees Celsius. 7.Not easy to form dirt: It can’t form dirt in the medium with PH value of 9 or above 8.Long life-span:It can maintain more than 70% mechanical properties after it is buried and used for 50 years. Applications: 1.transport powder and coal ash in thermal power plant 2.transport mine tailings and slurry ,metallurgical mines,in the mining industry 3.transport pulverized coal and coal-water slurry of coal preparation plant in the coal industry 4.transport mud and corrosive media with slag in the chemical industry 5.transport crud oil,petroleum, food and natural gas Guorun uhmwpe pipes’s outer diameter is from 65 mm to 800 mm;wall thickness is from 8mm to 38 mm
1. Wear resistance;
2. Impact resistance;
3. Corrosion resistance;
4. Good self-lubrication
9. Easy installation:The weight of unit length of UHMWPE pipe is only one-eighth of the steel pipe, it is possible whether it is welded or connected by flange
UHMWPE Pipe Specification Table
Diameter
0.6Mpa
0.8Mpa
1.0Mpa
1.25Mpa
1.6MPa
2.0Mpa
mm
Wall Thickness(mm)
Wall Thickness(mm)
Wall Thickness(mm)
Wall Thickness(mm)
Wall Thickness(mm)
Wall Thickness(mm)
300
10
12
15
18
23
27
315
10
12
15
19
24
29
325
10
13
16
19
24
30
350
11
14
17
21
26
32
377
12
15
18
22
28
35
400
12
16
19
24
30
36
415
13
16
20
25
31
426
13
17
20
25
32
536
16
21
26
23
560
16
22
27
33
630
19
25
30
37
652
20
26
32
38
710
21
27
34
800
23
31
38
