Auto Bluetooth DVR Rearview Mirror With Camera Parking Sensor

Specifications

Multifunction Auto Bluetooth DVR with Rearview Mirror Auto Camera and Parking Sensor
Wireless Bluetooth Auto DVR Alarm System

Car Bluetooth DVR Rearview Mirror with Camera Parking Sensor



Specifications:

Item No.: BT728

1) Bluetooth 2.0 + EDR, compatible with all Bluetooth enabled mobile phones

2) Caller ID indicate on 3.5" TFT display,support English name display

3) Voice dial and last number redial

4) Noise suppression and echo cancellation technology

5) AVRCP profile integrated, control the audio playback when used with Bluetooth

stereo mobile phone or Bluetooth USB dongle

6) Built-in microphone and built-in dual stereo louder speaker

7) Built-in FM frequency transmitter connect to your car stereo

8) Universal audio input for audio devices, such as iPod, MP3 to enjoy wireless

stereo listening

9) FM earpiece is available,it provided for total private conversation

10) Parking sensor system is available

11) Rearview with camera

12) Wireless parking sensor and camera is available

13) Video in connector for video source display

14) Easy installation, the mirror simply clips over the top of your existing mirror

15) Phone book for max.200 address list.

16) Select last 10 calls dial-back from Bluetooth mirror



DVR Specification:

1.Storage type: SD card up to 32GB

2.Video/Audio compressed format: AVI

3.Video resolution: VGA 640 X 480

4.Video speed: 30FPS

5.Recording time: 80 minutes around/2G



DVR Function(Optional)

This device will offer you a record for video and audio while driving.

When the car started, the system automatically start working.The yellow LED will light.

To check DVR working state, press PLAY button 3 seconds to open the DVR video on    mirror,press"PLAY"button 3 seconds again to close the DVR video.

When recording,press SW1 2 seconds to stop recording,the green LED will be off.

When recording,shortly press SW2 to play back.

When replaying,shortly press SW1 to select file,then shortly press SW2 to play back,shortly press SW2 again to pause,and so on.

When replaying,press SW2 2 seconds to exit and back to record.

The yellow LED will be off if there is no memory card or memory card is error.

The system will stop recording and save the last file when the car is turned off.

-?Rotatable wide-angle camera it can be turn left/right and up/down.

Recording Mode: Subparagraphs file recording,2 minutes for per file,when memory is full the new ile will cover the    earliest one.

DVR Time Setting:Making a SETTIME. TXT file into SD card,the file content:yyyy.mm.dd hh:mm:ss Y (for example:   2010.01.07 10:42:30 Y).When DVR power on,the time will be set and shown on display.



Packing Information:

BT728 * 1pc
Control Box * 1pc
Parking Sensor * 4pc
AC Cable * 1pc
Camera * 1pc

Video Cable * 1pc
Earpiece * 1pc
Sensor driller * 1pc
User's manual * 1pc



Color Box: 33.2x20x6.5 cm

N.W.:1.6 KG,with parking sensor

N.W.:1.1 KG(without parking sensor

Carton Box (10 sets): 67x34.7x21 cm

G.W.: 17 KG,with parking sensor

G.W.: 12 KG, without parking sensor)
