Full Colour p5 Indoor Led Display
| Parameter | Value |
| Pixel Configuration | SMD2020 |
| Pixel pitch (mm) | 5 |
| Pixel matrix per panel | 104*208 |
| Pixel density (pixelsm) | 43264 |
| Cabinet Dimensions(L*W*H) mm | 500*1000*83.3 |
| Module Dimensions(L*W*H) mm | 250*250 |
| Panel material | Aluminum or iron |
| Cabinet weight (kg/panel) | 13 |
| Colour grayscale (bit) | 12-16bit |
| Gray scale per colour (level) | 16384 |
| Refresh rate (hz) | 1920 |
| Driving type | 1/16 |
| Signal transmission distance (m) | cats cable: single mode fiber: |
| Brightness (nit) | 1000/5000 |
| Optimal horizontal viewing angle (degree) | 160 |
| Optimal vertical viewing angle (degree | 160 |
| Ac input voltage (v) | Ac100-240v |
| Ac input frequency (hz) | 50/60 |
| Ac input power maximum value (wm) | 270/420 |
| Ac input power typical value (wm) | 90/140 |
| Storage temperature (℃) |
-40-60 |
| Work temperature (℃) |
0-45 |
| IP rating (front/rear) | IP40/IP21 |
| Storage humidity (rh) | 10%-90% non -condensing |
| Working humidity (rh) | 10%-90% non-condersing |
| Lifetime Typical value (hrs) | 100000 |
PACKAGE:
