WS-C3560G-48PS-E Cisco

@ Cisco WS-C3560G-48PS-E Media & Performance Performance: 64Gbps Switching Fabric Performance: 38.7Mpps Forwarding Rate for 64-byte Packet Cisco WS-C3560G-48PS-E I/O Expansions Number of Expansion Slots: 4 Expansion Slots: (4 Total) SFP (mini-GBIC) Cisco WS-C3560G-48PS-E Network & Communication Flow Control: IEEE 802.3x (Full-duplex) Layer Support: 4 Layer Support: 3 Layer Support: 2 Address Table: 12K MAC Addresses Maximum Cisco WS-C3560G-48PS-E Management & Protocols Manageable: Yes Management: @ SNMPv1, SNMPv2c, and SNMPv3 @ policy management @ Command-line interface (CLI) @ Resource Manager Essentials @ Web-based management @ Cisco Network Assistant Software @ Four thousand VLAN IDs are supported @ Management console port: RJ-45-to-DB-9 cable for PC connections @ Service Assurance Agent (SAA) support facilitates service-level management throughout the LAN. @ Up to 1024 VLANs per switch or stack and up to 128 spanning-tree instances per switch are supported @ Embedded Remote Monitoring (RMON) software agent supports four RMON groups (history, statistics, alarms, and events). @ VLAN trunks can be created from any port, using either standards-based 802.1Q tagging or the Cisco Inter-Switch Link (ISL) VLAN architecture. @ Remote SPAN (RSPAN) allows administrators to remotely monitor ports in a Layer 2 switch network from any other switch in the same network. Protocols: TFTP Protocols: RADIUS Protocols: NTP Protocols: SSH Protocols: TCP/IP Protocols: TACACS+ Protocols: PIM-SM Protocols: PIM-DM Protocols: BGP v4 Protocols: EIGRP Protocols: DVMRP Protocols: STP Protocols: MSTP Protocols: ARP Protocols: RIP Protocols: DTP Protocols: DHCP Protocols: LACP Protocols: WCCP Protocols: IGRP Protocols: OSPF Protocols: RIP v2.0 Protocols: RIP v1.0 Protocols: HSRP Protocols: UDLD Protocols: RSTP Protocols: PAgP Security Features: @ Secure Shell (SSH) Protocol Version 2 @ (IDS) to take action when an intruder is detected. @ One thousand access control entries (ACEs) are supported @ TACACS+ and RADIUS authentication enable centralized control of the switch @ IEEE 802.1x allows dynamic, port-based security, providing user authentication @ Port security secures the access to an access or trunk port based on MAC address @ Unicast MAC filtering prevents the forwarding of any type of packet with a matching MAC address. @ Port-based ACLs (PACLs) for Layer 2 interfaces allow application of security policies on individual switch ports. @ Cisco security VLAN ACLs (VACLs) on all VLANs prevent unauthorized data flows from being bridged within VLANs. @ Bidirectional data support on the Switched Port Analyzer (SPAN) port allows the Cisco Secure Intrusion Detection System. Cisco WS-C3560G-48PS-E Memory Standard Memory: 128MB Memory Technology: DRAM Flash Memory: 32MB Cisco WS-C3560G-48PS-E Software Operating System: @ Enhanced Multilayer Software Image (EMI) installed @ Enhanced Multilayer Software Image (EMI) installed Cisco WS-C3560G-48PS-E Controls/Indicators Status Indicators: Per-port status LEDs: @ Link integrity @ Disabled @ Activity @ Speed @ Full-duplex indications @ PCE applied @ PCE error @ PCE disabled indications System-status LEDs: @ System @ RPS @ Link status @ Link duplex @ Link speed @ PCE indications Cisco WS-C3560G-48PS-E Reliability MTBF: 147000Hour Cisco WS-C3560G-48PS-E Power Description Power Consumption: 370 W Maximum PCE Power Consumption: 590 W Maximum Cisco WS-C3560G-48PS-E Environmental Conditions Temperature: 0 degrees C (32.0 degrees F) to 45 degrees C (113.0 degrees F) Operating Temperature: -25 degrees C (-13.0 degrees F) to 70 degrees C (158.0 degrees F) Storage Humidity: 10% to 85% Non-condensing Relative Humidity Operating Altitude: 10000 ft Operating Altitude: 15000 ft Storage Thermal Dissipation: 220 W @ 690BTU/h
