Tipper Truck 4x2 With Competitive Price

SINOTRUK

HOWO 4x2 tipper Truck

Model

ZZ3167M4611

Left hand (right hand available)

Engine

WD615.87,

266hp ,

9.726L ,

Euro Ⅱ

Rated Power

Kw/rpm

213/2200

Max Torque

Nm/rpm

1160/1100-1600

Type : 6 cylinder inline , turbo charger inter cooled , 2 valves , postposition supercharger.

Cabin

HW76 , lengthen cabin , single sleeper , adjustable steering wheel , VDO panel , control module , safe-belt with 2 locks , outer sun shade .

Transmission

SINOTRUK HW series 10 speeds , HW15710 , main and auxiliary box structure , the main box double shaft Planetary reducer , with power takeoff .

Front Axle

HF9 drum , rated loading 9T

Rear Driving Axle

HC16 double reduction (central reduction + hub reduction) , ratio : 5.73 . (4.8 available)

Suspention

Front&rear suspension are semi-elliptic leaf springs + shock absorber + stablizer

Steering System

ZF8098 steering gear box , ZF power steering pump , system pressure : 18Mpa .

Brake System

Driving brake : dual circuit compress air brake ;

Parking brake : spring energy , compressed air operating at rear wheel ;

Auxiliary : EVB + engine exhaust (ABS is available)

Electronic System

CAN bus control , voltage : 24V , alternator : 1540W , starter : 7.5KW , battery : 12V/165Ah , 2pcs

Tyre

12.00-20 ;

11.00-20 available

Fuel Tank Capacity             L

300 L

Payload                        Kg

8000/6780

Gross Vehicle Weight          Kg

16000

Rated Loading Weight        Kg

7870

Overall Size                 mm

8127X2496X3150

Chassis Size                 mm

7310X2496X2958

Axle Base                    mm

4600

Front/Rear Suspension      mm

1500/(2027/1210)

Wheelbase                  mm

2022/1850

Min. Ground Clearance      mm

314

Approach/Departure Angle     °

19/(22/38)

Max. Speed                  Km/h

75

Max. Climbing Capacity        %

≥50

Min. Turning Circle            m

17

Cargo Box Inside Size        mm

5410x2300x800

Cargo Box Volume              m³

9.9

Remarks

WD615.62available

ABOUT HOWO

·Comfortable & hommization design idea.

• Independent developed technology.

COLOR ( OPTIONAL )

     YELLOW

WHITE

BLACK

BLUE

GREEN

RED
