CNC Turning Service
At Kang Ding, we provide you with high quality CNC turning services using our brand-new CTX-beta-1250 turning mills imported from the Germany. These CNC turning mills are hybrid machines,turning length from 300 to 2,000 mm, chuck diameter between 165 mm and 630 mm, rod through diameter from 51 mm to 102 mm, combining the best features of lathes and mills to provide true 5-axis machining for even greater efficiency and more complex geometries on your project.
When combined with our other CNC machining, fixture design, small batch manufacturing, prototyping and surface treatment services, you can get great parts for up to 60% less than our competitors while keeping the quality you expect and deserve.
What Is CNC Turning?
Turning involves holding the metal parts in a horizontally-mounted, adjustable spindle and Vice spindle. As the metal parts rotates, machining straight cylindrical, diagonal cylinder, groove, arc and various threads, contour, groove, thread, worm and other complex parts, with linear interpolation, circular interpolation of various compensation functions. On our CTX beta 1250 turning mills, an extra axis of movement allows us to work perpendicular to the lathe spindle for making square faces or boring holes. This opens up many new machining possibilities.
Turning is used for any rotationally symmetrical shape, to remove material quickly while leaving an excellent surface finish that sometimes requires no post-processing.
Why Choose CNC Turning?
CNC turning is the fastest way to remove large amounts of material on rounded stock. It’s also ideal for larger production runs when coupled with an automatic bar feeder that provides an uninterrupted supply of raw material into the machine.
1. High precision, with a stable processing quality;
2. Can be multi-coordinate linkage, can process the shape of complex parts;
3. Processing parts change, generally only need to change the NC program, can save production preparation time;
4. Machine automation is high, can reduce the labor intensity;
5. Mass production, product quality easy to control;
6. Machining center, with a dozen to dozens of different tools, it can be a one-time car, milling, drilling, hinge and many other cutting.
CNC turning is the only industrial process to choose when making production volumes of concentric shapes or threaded features. And, because of the rigid construction of these machines there is little vibration, which means CNC turning can offer high levels of dimensional accuracy with excellent surface finishes.
CNC Turned processing of what material ?
While potentially any solid, stable material can be turned, we work with hard plastics and 316 | 304 stainless steel, carbon steel, alloy steel, alloy aluminum, zinc alloy, titanium alloy, copper, iron, plastic, acrylic, POM, UHWM and other raw materials, can be processed into a round, complex structure of the complex parts. See more information on available materials.
Note that some hardened steels may be too hard to CNC turn, or else will require specialty cutting tools and longer processing times. Soft elastomers or plastics may also be impossible to turn since they cannot be held in a fixed position or would change in shape under the pressure of the cutting tool.
What Are The Advantages of Working With Us?
At Kang Ding, we have a complete CNC machining service waiting to start making your CNC machined parts. Here are some of the reasons you won’t be disappointed when working with us:
• We’re located in DongGuan China, close to major shipping ports in Shenzhen and Hong Kong, so your parts can be delivered fast and at a competitive price, for you to open up the city to win the initiative.
• We have world-class CNC turning mills and cutting tools imported from the Germany.
• We work in a clean, well-lit and climate-controlled production area, certified to ISO9001:2008, IECQ-QC080000, TS16949, ISO14001 and BS-OHSAS 18001 standards.
• You will have an international team of skilled technicians, managers and toolmakers working for you.
• We’re able to keep costs down while providing unmatched precision and quality without cutting corners.
• We use advanced CNC software from Autodesk to control our automated processes.
• Incoming quality inspection and testing of raw materials ensures the integrity of our supply chain, so you get exactly the materials you specified.
• We are experts in prototyping and small batch manufacturing, so quick set-ups and rapid production is in our DNA.
• Our CNC turn milling services are designed to work in tandem with our many other metal fabricating and surface treatment capabilities, to provide you with a comprehensive one-stop rapid manufacturing.
