The machinery is suitable to the production of nonwoven fabric by spun-laid and hot-rolled reinforcement. With PP as its main material; color master batch,antioxidant,fire retardant as its additives to produce nonwoven fabric with different colors and different elements to fit the needs of different usages.
We can provide 3 main models according to the effective width: 1.6m,2.4m,3.2m(also can do it according to customer's requirements)
Description of pp nonwoven machine
| Item | specifications |
| Effective breadth(mm) | 2400 |
| Production capability(T/Y) | 2200 |
| Weight range(g/m2) | 9-200gsm |
| Installed capacity(KW) | 220 |
| Filament denier | <=2.3D |
| Screw diameter(mm) | 130-170 |
| Length-diameter ration | 30:1 |
The main processing as following:
Parts of spunbonded nonwoven fabric production line:
Screw extruder---Rim charge auxiliary screw and recycling device---Spinning beam ---filter---metering pumping ---monomer suction device---Quenching air chamber ---stretching device---Calendering ---Rounding ---Tension device---Winder and suction system
Spunlaid process and technical flow chart
Additive(recycling waste edge)---raw material---Melting---Filtering ---Measuring---Spinning---Cooling---Strectching---Web forming ---Calendering---Rounding---Final Products
The non-woven fabric produced by our machinery has high strength, good softness, innocuity, bacterium – proof,corrosion resistance, high level draw strength & elongation rate. The fabric can be made of different color, different grams,and different lines according to users’ requirement.
