Cotton Carding Machine
Use and characteristics:
unique patented three-roller stripping cotton;
increase in the gill plate carding roller;
After the first three additional two fixed cover;
brake fast-Astoria;
used Step-pressure roll;
use of Adolf timing belt drive;
about closed-end security cover;
Main specifications:
the scope of application |
apply to the local cotton and chemical fiber spinning pure or blended with Mianjuan feeding. |
|
quantitative production |
3.5 ~ 6.5 g / m |
|
production |
45 kg / h |
|
working width |
1000 mm |
|
additional pieces of comb |
roller carding a board |
|
Cover fixed after 2 | ||
|
cover fixed before the | ||
drawing a multiple of total |
67 ~ 120 |
|
Spurs roll diameter of the work |
Φ250 mm |
|
barbed roller speed of the work |
cotton |
1070 to / |
Fiber |
980 / |
|
work of the cylinder diameter |
Φ1289 mm |
|
cylinder speed of the work |
Cotton |
360 / |
Fiber |
330 / |
|
the work of Adolf diameter |
Φ706 mm |
|
speed of the work of Adolf |
21.3 ~ 38.2 to / |
|
cover the number kan |
40/106 |
|
flat rate of |
Cotton |
177 214 266 mm / sub |
Fiber |
81 98 122 mm / sub |
|
sliver application of the tube |
Φ600 × 900 mm |
|
dust |
Cylinder triangle-Astoria, gill cover roller cover, curtain delivery vehicles belly 3 miscellaneous cleaning |
|
suction air flow in a row |
1300 m 3 / h |
|
wind |
-500 ~ -600 Pa |
|
total power installed capacity |
4.4 kW |
|
main motor |
3.3 kW |
|
Adolf drive motor |
1.1 kW (frequency, a significant number of users may choose to use) |
|
area (length × width) |
3809 × 2092 mm |
|
weight of the whole machine |
About 4500 kg |
|
