Design Performance and dimensions referring to BS EN733/ DIN24255.
Structure: Horizontal, Axial End-Suction, Single-Stage, Single-Suction, Volute Casing, Back pull-out, Centrifugal Pump
Flange: DIN2501 (ISO7005.2 / GB/T17241.6 PN1.6) standard, ANSI B16.5 Class150lb optional
Rotation: Clockwise viewing from the drive side
Material
Casing- Cast Iron standard, Ductile Iron, Stainless Steel optional
Impeller- Bronze standard, Cast Iron, Stainless Steel optional
Shaft- ASTM420 standard, ASTM304, ASTM316, ASTM1045 optional
Shaft Seal- Mechanical Seal standard (Carbon-Ceramic/Viton standard, Caron-Sic/Viton optional) , Gland Packing optional
Operating Range
Flow Rate (Q) 2-1100m3/h
Head (H) 2-150m
Speed 1450 or 2900 rpm (50Hz)
1750 or 3500 rpm (60Hz)
Temperature -10℃ to 105℃
Working Pressure 10 Bar standard, 16 Bar on request
Diesel engine driven brand,
Cummins, Deutz, Ricardo, Yangdong diesel engine and so on
