Help Center16 Port Fiber Optic Termination Box FDB White With SC/APC PLC Splitte
Related Products
-
Duplex SC/APC Adapter FTTH Socket Panel Wall Outlet Box Plastic ABS Terminal BoxNegotiableMOQ: 1000 Pieces -
SC/APC Adapter FTTH Socket Panel Wall Outlet Box Plastic ABS Terminal BoxNegotiableMOQ: 1000 Pieces
-
FTTH Socket Panel Wall Outlet Box Plastic ABS Terminal BoxNegotiableMOQ: 1000 Pieces
-
SC/UPC FTTH Socket Panel Wall Outlet Box Plastic ABS Terminal BoxNegotiableMOQ: 1000 Pieces
-
SC/UPC FTTH Socket Panel Wall Outlet Box Plastic ABS Terminal BoxNegotiableMOQ: 1000 Pieces
NT-FTB016 Type Optical Termination Box
NT-FTB011 Type Optical Termination Box is designed to connect feeder/distribution cable to subscriber's
drop cable using PLC splitter in FTTx networks. NT- FTB011 has 2 input ports and 16 output ports on the bottom
and it is easy to install on the wall or pole. The rear tray is for splicing a fiber of feeder cable with PLC splitter and
the front tray is for connecting subscriber's drop cable through adaptor plate on the tray.
Features
1) User familiar industry interface, using high impact plastic
2) Can accommodate 1x8 PLC splitter and 1x16 PLC splitter
3) Ultra violet resistant and rainfall resistant
4) Up to 16 FTTH drops
5) Wall and pole mountable
6) 2 inlet ports, 16 outlet ports
Specifications
ITEM |
Values |
|
Dimensions |
L : 225 ㎜, W : 302 ㎜, H : 71 ㎜ |
|
Weight |
1.3 ㎏ |
|
Cable input port |
Max. 2 ports (Max. dia. : 12 ㎜) |
|
Cable output capacity |
Max. 16 ports (Max. dia. : 3 ㎜) |
|
Max. capacity |
12 core |
|
Operation Temperature |
-40 ~ +85℃ |
|
Tensile Strength |
≥ 450 ㎏/㎠, @10 ㎜/min |
|
OTB Resin |
Impact Strength |
35 ㎏㎝/㎠ (normal temp.), 10 ㎏㎝/㎠ (-30℃) |
Flexural Strength |
≥ 450 ㎏/㎠, @10 ㎜/min |
|
Send Inquiry to This Supplier
