Tunnel / Pathway / Park waterproof High Power LED Flood Light 120 W

Delivery Time:5-12 working days
Certification:CE,ROHS and ISO9001:2008

High Power LED Flood Light 120W with Bridgelux COB LED Chip and Meanwell driver.

Outlook

2. Application
Projector / Floodlight
Tunnel Lighting / Pathway Lighting / Park Lighting
Signboard Lighting


3. Features

1) Bridgelux COB LED Chip inside, High light out put>90Lm/W, High CRI, Ra>70.

2) Patent DIWL Lens, high efficiency>92%, Anti-glare Diamond quality;

3) World Top class Mean Well CLG or HLG series LED driver inside, PF>0.95.
4) Multi-Chip on Lead Frame, Single Module LED Package Design
5) System Design Integrating Power Supply, LED Light Engine, and Heat Sink
6) Over Current, Over Voltage, Over Heat, Thunder Protection
7) Long lifespan for LED 50,000 hrs
8) 100% Recycle, No Pollution, and UV, IR

4. Specification

Item No.	LY-FL29120PW	LY-FL29120WW	LY-FL29120NW
Inptut voltage	AC100V～240V      50/60HZ
System consumption(W)	≤125	≤125	≤125
Light Fixture Luminance (lm)	9800	8600	9500
LED type of COB	Bridgelux  45mil/38mil	Bridgelux  45mil/38mil	Bridgelux  45mil/38mil
Beam Angle	10°/24°/38°/60°/90°	10°/24°/38°/60°/90°	10°/24°/38°/60°/90°
CRI	＞70	＞70	＞70
Color Temperature(CREE)	5000k	2700k,	4000k
Meterial	Aluminum+PMMA
Driver	MW      CLG-150-36A   /   HLG-150-36A
Lifespan(hrs)	＞40000
IP Rating	IP65
LED Package	12X10W	12X10W	12X10W
Floodlight Size(mm)	455X315X190	455X315X190	455X315X190
NET Weight(KG)	8.9	8.9	8.9

5. Photometry

AAI Figure


6. Operation and Storage Condition

Operation Ambient Temperature -40 to +60°C, Relative Humidity 20~90%
Input Voltage 100~240V AC, 50/60Hz
Storage Ambient Temperature -40 to +85°C, Relative Humidity 5~95%
Mounting Height : Suitable for 8~10m height

7. Certificate

LED Lighting Certificated with CE
Power System Certificated with UL
The Whole Floodlight Certificated with CE
