Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | CH-series |
Product Description
Certification:CE,ISO
Single Car 500kg Rack And Pinion Hoists CH500 Capacity With Mast Hot-dip Galvanized
Quick Detail:
Name | Other Name | Brand Name | Control |
Rack and pinion hoist | Rack and pinion hoist CH500 | BORUIDA | DOL and FC |
Loading Capacity | 500kg | Certificate | CE |
Description:
Rack and pinion hoists are designed from the drawing board not only to excel as people carriers in multiple applications, but also to be able to handle materials of loads up to 3,200 kilograms. All rack and pinion hoists are built to last in the harshest environments.
Applications:
Rack and pinion hoists are built to withstand harsh environments and installations with or without an existing hoist shaft.
Specifications
Standard technical datas of single car :
Parameter | CH300 | CH500 | CH750 |
Rated | 300 | 500 | 750 |
Rated lifting speed | 0~40 | 0~40 | 0~40 |
Rated passenger number | 12 | 18 | 24 |
Max. lifting height(m) | 150 | 200 | 200 |
Engine power(kW) | 1*5 | 2*5 | 2*7.5 |
Car inner dimension | 1*0.8*2.2 | 1.2*0.8*2.2 | 1.5*1*2.2 |
Car weight (kg) | 527 | 595 | 689 |
Mast section weight | 55 | 55 | 125 |
Mast section dimension (mm) | 450*1508 | 450*1508 | 450*450*1508 |
Safety device type | SAJ30-1.2 | SAJ30-1.2 | SAJ30-1.2 |
Hanger rated lifting capacity | 125 | 125 | 125 |
Rack module | 5 | 5 | 5 |
CH series rack and pinion hoists:
1). Car load capacity: 300kg~750kg;
2). Lifting speed:30m/min, 0~40m/min;
3). Increased lifting height on request;
4). Mast section: Painted or hot dipped zinc
5). Car:double car
6). Recommended car inner dimensions (L*W*H): 1*0.8*2.2 m,1.2*0.8*2.2 m,1.5*1*2.2 m, according to requirements of customers;
7). Motor and reducing device: Made in China, or uses SEW according to requirements
8). Color of car: Yellow, red, blue or your request
9). Car load capacity: 300kg, 500kg, 750kg
10). including VFD or without VFD.
Competitive Advantage:
1). Ideal for tough environments
2). No enclosed hoistway or shaft needed
3). Suitable for both indoor and outdoor installation
4). Small footprint
5). No machine room required
6). Few changes required to buildings and structures
7). Easy to retrofit on existing buildings or structures
8). No lifting height limit
9). High capacity and speed
10). Accurate levelling at landings
11). Safe descent during a power outage
12). Durable and easy to maintain
13). Wide range of optional equipment and functions
