Help CenterKYL-600L Wireless Voice and Data Transceiver Radio Modem
Related Products
-
KYL-668H Data Transmission Radio Modem With VHF Frequency and 20km RangeUS$ 195 - 195MOQ: 2 Pieces -
KYL-300H Wireless Transceiver Radio Modem With UHF Frequency and 10km RangeUS$ 110 - 110MOQ: 2 Pieces
-
KYL-300L Low Power RF Transceiver Data Module WithUHF Frequency and 3000m RangeUS$ 45 - 45MOQ: 2 Pieces
-
Radio Modem/wireless Data Radio Module With 5W Power OutputUS$ 110 - 110MOQ: 2 Pieces
-
Low Power Data Radio Modem With VHF Frequency and 1W Output PowerUS$ 60 - 60MOQ: 50 Pieces
1. Specifications:
* Operating Voltage: DC 5V
* Carrier Frequency: VHF/UHF 230-450MHz
* Interface: standard RS-232/RS-485/TTL Selectable
* Baud Rate: 1200/2400/4800bps Selectable
* Channel spacing: 25kHz
* Frequency stability: ±2.5ppm
* Modulation: FSK; Channels: 16
* Impedance: 50Ω
* Transfer distance:3km(BER=10-3@9600bps);
* Temperature: -25℃~+65℃
* Size: 70x46x12mm(without antenna port)
* Weight:180g
2. Receiver:
* Receiving sensibility: ≤0.25μV (12dB SINAD)
* Signal-to-Noise: ≤-40dB
* Adjacent channel selectivity: ≥70dB
* Intermodulation rejection: ≥65dB
* Clutter and images rejection: ≥70dB
* Receiving current: 50mA
* Audio Output power: 0.5W(8Ω,10% distortion)
* Receiving distortion: ≤3%
3. Transmitter:
* RF power: ≤500mW (1W/2W customized)
* Transmitting current: 300mA
* Modulation: FFSK
* Audio distortion: ≤3%
* Frequency deviation: ±5.0kHz
* Adjacent channel power: ≥70dB
* Transmitter startup time: ≤50m
* Surplus Frequency Modulation: ≤-40dB
* Modulation distortion: ≤3%
* Modulation sensibility: 5mV
* Transmission distance: 3Km
* Volts D.C.: 5V (12V optional)
