mobile jaw crusher
- 50 Meter / Meters per Month
- T/T L/C D/P D/A
- 7 days
- Steel structure
- New Product Galvanized Corrugated Sheets Corrugated Tin Sheet Steel Roofing Sheet
- Z90 Hot DIP Cold Rolled Textured Exterior Pre-painted Galvanized Steel Coil
- ppgi coils manufactured in china ppgi sheet galvan steel coil ppgi ppgl steel coil customization
- color coated ppgi steel coils wood grain ppgi galvanized steel coil
- High Quality Corrugated Galvanized Steel Roofing Sheet Price Gi Corrugated Steel Sheets
Product Details
Brand Name: | Jianye | Place of Origin: | China | Model Number: | PE |
Product Description
This product series is used in primary crushing of material.It processes various kinds of material with crushing compresion strength not more than 320mp.It features firm structure,stable performance,large capacity,even producing granularity,convenient maintenance and economical running expense.It has been widely applied in area of mining,construction material,smelting,railway,high grade road surface,water conservancy,etc.
Jaw Crusher Operating principle:
The motor drives the belt wheel, and makes movable jaw up and down by eccentric shaft. When the movable jaw rises, the angle between the fixed jaw and movable jaw gets larger, and the materials can be crushed to reach the crushing target. When the movable jaw is down, the angle between the fixed jaw and movable jaw becomes smaller. The movable jaw plate leaves the fixed jaw plate under the function of drawbar and spring, and then the crushed materials are discharged from the lower outlet of the crushing cavity.
Jaw Crusher Specification:
Model
|
Feed Opening
(mm) |
Max. Feed Size
(mm) |
Capacity
(t/h) |
Power
Consumption (kw) |
Discharge Opening
(mm) |
Overall Dimension
(L x W x H) (mm) |
PE-150×250
|
150×250
|
125
|
1-5
|
5.5
|
10-40
|
758×758×794
|
PE-250×400
|
250×400
|
210
|
5-20
|
15
|
20-60
|
1500×1400×900
|
PE-400×600
|
400×600
|
340
|
16-65
|
30
|
40-100
|
1700×1800×1600
|
PE-500×750
|
500×750
|
425
|
50-100
|
55
|
50-100
|
1890×1940×1870
|
PE-600×900
|
600×900
|
500
|
50-120
|
55
|
65-160
|
2395×1843×2230
|
PE-750 ×1060
|
750×1060
|
630
|
52-180
|
110
|
80-140
|
2775×2426×2840
|
PE-800×1060
|
800×1060
|
640
|
136-230
|
110
|
100-200
|
2500×2472×2810
|
PE-900×1200
|
900×1200
|
750
|
140-260
|
110
|
95-165
|
3400×3200×3500
|
PE-1000×1200
|
1000×1200
|
850
|
315-342
|
110
|
195-265
|
3335×3182×3430
|
PE-1200×1500
|
1200×1500
|
1020
|
400-800
|
160
|
150-300
|
4200×3732×4620
|
PE-250 ×750
|
250×750
|
210
|
15-30
|
22
|
15-70
|
1400×1300×1350
|
PE-250×1000
|
250×1000
|
210
|
16-52
|
30
|
25-60
|
1600×2000×1500
|
PE-250 ×1200
|
250×1200
|
210
|
20-60
|
37
|
25-60
|
1900×2200×1500
|
PE-300×1300
|
300×1300
|
260
|
30-70
|
55
|
30-90
|
1800×2300×1700
|
