Double Sides P12 Outdoor LED Display Screen With Front Service

Name: Double Sides P12 Outdoor LED Display Screen With Front Service
Brand: Newstar-LED
SKU: 153374888
Availability: InStock

US$ $1 - $1 MOQ: 1 Piece

Key Specifications

Brand Name:

Newstar-LED

Place of Origin:

China

Model Number:

NS-OR-DD-P12

Shenzhen Newstar Optoelectronics Co., Ltd,

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name Newstar-LED

Place of Origin China

Model Number NS-OR-DD-P12

Delivery Time:8-25days after received the payment
Certification:CE, RoHS, UL, FCC, ISO

Quick Detail:

1. Front opening door

2. Save maintenance space

3. Fully waterproof IP65

3. Clear vivid image quality

4. Easy Installation & Using

5. Brightness≥6000 cd/m2

6. Long Lifespan > 100,000 hours

Double Sides P12 Outdoor LED Display With Front Service

Description:

1. Front service of cabinet for easy maintenance

2. Different video frequency can be changed freely at the same time, and the image can be enlarged and

reduced

3. Play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and

other equipment

4. High brightness, and can be adjustable, meets the need of changing requirement of customer in

environment

Applications:

Commercial advertising: Square, Road side, High way, Airport, Wharf, Hotel, Restaurant etc

Specifications:

1. Outdoor LED Display Technical Parameter

Model No.	NS-OR-DD-P12
Pixel Pitch	12mm
Module Size	192 mm ×192mm
Module Resolution(Pixel)	16 dots×16dots
Pixel Density	6944 dots/m2
LED Type	3mm Oval Lamp
Pixel Configuration	1R1G1B
Wavelength (R.G.B)	R:625±2nm G:525±2nm B:470±2nm
Drive Mode	Dynamic 1/4 Duty Constant Current
Cabinet Size	1152×768×150mm
Cabinet Resolution	96dots×64dots
Brightness	≥6000 cd/m2
Contrast	≥2000:1
Viewing Angle	110°(Horizontal )/45°(Vertical )
Best Viewing Distance	10~300 m
Grey Scale	10bits/1024levels
Color Capability	16777216
Color Temperature	5000-9300K
Maximum Power Consumption	1000 W/m2
Average Power Consumption	350W/m2
Working Voltage	AC220V/110V s±15% 50-60 HZ
Frame Frequency	≥60HZ
Refresh Frequency	≥240HZ
Brightness Correction	Pixel, Module, Cabinet Correction
Operating Temperature	Static:-40°C ~ +85°C Working:-20°C ~ +60°C
Operating Humidity	10-90% RH
LED Lifespan	100,000 hours
MTBF	≥50000 hours
Computer Operation System	Win 98/ Win XP/ Win 2000
Video Signal Input	RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite
Video Signal Output	RF, S-Video, GB, RGBHV, YUV, YC etc.
Graphics Card
