Home > Products > Die-Casting LED Display > P5.33 RGB Die-Casting LED Display ,IP21,SMD 3 In 1 LED Display Board

P5.33 RGB Die-Casting LED Display ,IP21,SMD 3 In 1 LED Display Board

FOB Price

USD $ $1 - $ $1 / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Newstar-LED		Place of Origin	China
Model Number	LS-5

Product Description

Delivery Time:8-25days after received the payment
Certification:CE, RoHS, UL, FCC, ISO

P5.33 RGB Die-Casting LED Display , IP21 SMD 3 In 1 LED Display Board

Quick Detail:

1. Brilliant contrast ratio, high resolution/high definition

2. Super light and can be installed by one person

3. Super uniformity and no mosaic

4. Available product model: P3.84, P4, P4.8, P5.33, P6.

5. Waterproof Level: IP21

6. Brightness(cd/m2)>2000nit

Description:

1. Supper thin Design

576 x 576 x 83mm per panel.

2. Fast and simple Assembly

No tools needed, one person can install at least 70 cabinets per hour. One person can finish the whole

process alone.

3. Light Weight

One cabinet only weights 9 KG, 34KG for one square meter.

4. Aluminum Die casting Materials

good appearance, anti-corrosiveness . 9 kg/panel,

Applications:

Commercial advertising, mobile media, night club, entertainment events, business establishments, such as

banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,

shopping malls, railways, airports, harbors, etc;

Specifications:

1. Indoor LED Display Technical Parameter

Model No.	LS-5
Pixel Pitch	5.33mm
Module Size	288*288mm
Module Resolution(pixels)	54*54
Panel Size	576mm×576mm
Panel Resolution(pixels)	108×108
Pixel Configuration(RGB)	1R1G1B
Pixel Density(pixels/m2)	35,200
Brightness(cd/m2)	2,000
Best Viewing Distance(m)	5-100
Max.Power Consumption(W/m2)	900
Waterproof Level	IP21
Wavelength	R 620-625 G 520-525 B 470-475
LED SPEC	3528
Viewing Angle	140°(H)/140°(V)
Operating Temperature	–40~60°C
Video Frame Rate(Hz)	≥60HZ
Display Refresh Rate(Hz)	≥300HZ
Grey Level(colors)	16.7million
MTBF	≥50,000 hours
Lifespan	≥100,000Hours
Working Voltage	220V±15% OR 110V±15%
Drive Mode	Constant 1/9
Graphics Card	DVI Graphics card
Video Signal	RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control System	LINSN
Software	LED studio 10.0
Installation	Wall mount, hung and stand structure

2. Indoor LED Display Module

Dimensions (w x h)	288mmx288mm	Resolution (w x h)	54 x 54
Pixel pitch	5.33mm	Pixel Density	35,200/㎡
Pixel Configuration	1R1G1B 3 IN 1	LED Type	3528 LED

3. Indoor LED Display Cabinet

Dimensions(w x h x d)(mm)

576x576x83

Module Quantity
