Sell High-speed Full-automation Plastic Vacuum Forming Machine
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Place of Origin:
China
Model Number:
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Sell Full-automation Self-cut Vacuum Forming MachineNegotiableMOQ: 1 Set -
Sell KED-680 Fully Automatic Hydraulic Cup (Bowl) Making MachineNegotiableMOQ: 1 Piece
-
Sell KDFJ-77/298 Twin Screw Starch Sheet Extruding UnitNegotiableMOQ: 1 Set
-
Sell TF-105/75-1000 Double Layer Extruding Machine UnitNegotiableMOQ: 1 Set
-
Sell High-speed Full-automation Vacuum Plastic Absorbing MachineNegotiableMOQ: 1 Set
Place of Origin
China
Model No.:ZS-680/1200
Product Origin:China
Brand Name:KICA
Price Terms:
Payment Terms:
Certification:ISO9001
Description:This machine can mold PVC, PE, PP, PET, HIPS and various thermoplasticity sheet into exquisite products in different shapes, such as packages & food containers. It can enable the products compliant with international standards. It improves the acceptance of the products dramatically. It provides following features: Faster molding; Two-way temperature control; Extra powerful cooling wind; Cooling water module plate; Servo-motor sheet sending system; Heaters are imported from Germany. This machine is simple and easy to use. It provides high productivity and is a sophisticately and widely used plastic vacuum forming machine. 1,Power Source: 380V 50Hz Three-phase four-wire system 2,Overall Power: 22kw 3,Gas Consumption: 1.4-1.6cbm/min 4,Water Consumption: 0.6-0.8cbm/h 5,Pressure Range: 0.6-0.8mpa 6,Water-ring Vacuum Pump: 100cbm/h 7,Ultimate Vacuum: 10mbar 8,Sheet Thickness: 0.10-1.0mm 9,Molding Area: 700x1220mm 10,Molding Length(terrace die): 250mm 11,Molding Length(concave die): 180mm 12,Sheet Width: 420-720mm 13,Selt-cut in the mould 14,Working Effciency: 6-12Times/min 15,Overall Cubage: 6700x1500x2480mm 16,Overall Weight: 4200kg
Product Origin:China
Brand Name:KICA
Price Terms:
Payment Terms:
Certification:ISO9001
Description:This machine can mold PVC, PE, PP, PET, HIPS and various thermoplasticity sheet into exquisite products in different shapes, such as packages & food containers. It can enable the products compliant with international standards. It improves the acceptance of the products dramatically. It provides following features: Faster molding; Two-way temperature control; Extra powerful cooling wind; Cooling water module plate; Servo-motor sheet sending system; Heaters are imported from Germany. This machine is simple and easy to use. It provides high productivity and is a sophisticately and widely used plastic vacuum forming machine. 1,Power Source: 380V 50Hz Three-phase four-wire system 2,Overall Power: 22kw 3,Gas Consumption: 1.4-1.6cbm/min 4,Water Consumption: 0.6-0.8cbm/h 5,Pressure Range: 0.6-0.8mpa 6,Water-ring Vacuum Pump: 100cbm/h 7,Ultimate Vacuum: 10mbar 8,Sheet Thickness: 0.10-1.0mm 9,Molding Area: 700x1220mm 10,Molding Length(terrace die): 250mm 11,Molding Length(concave die): 180mm 12,Sheet Width: 420-720mm 13,Selt-cut in the mould 14,Working Effciency: 6-12Times/min 15,Overall Cubage: 6700x1500x2480mm 16,Overall Weight: 4200kg
