Sell Flat-Top Continuous Foaming Production Line
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Place of Origin:
China
Model Number:
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Sell Horizontal Flexible Foam Cutting MachineNegotiableMOQ: 1 Piece -
Sell Horizontal Cutting Machine for Rigid Foam (Sawtooth Type)NegotiableMOQ: 1 Piece
-
Sell Horizontal Cutting Machine (Band Cutter Type)NegotiableMOQ: 1 Piece
-
Sell Vertical Cutting Machine for Flexible FoamNegotiableMOQ: 1 Piece
-
Sell Production Line Of Rigid Polyfoam Sandwich Panel With Color-steel FacingsNegotiableMOQ: 1 Piece
Place of Origin
China
Model No.:
Product Origin:China
Brand Name:
Price Terms:
Payment Terms:
Certification:
Description:Product Name: Flat-Top Continuous Foaming Production LinePlace of Origin: ChinaFeatures: 1) PU production equipment 2) Polyether, TDI and auxiliary devices stored in loading tanks 3) Operation process: a) Raw materials delivered into mixing head in a certain ratio b) Transferred to overflowing vessel and an adjustable falling plate for conveying c) In the process of conveying, foaming mixed materials are heated to cure d) Guaranteeing continuous production, paper-decoiling and paper-wrapping installations are synchronous with foaming process e) Continuously foaming plastic shall be cut into required lengths and moved to the ripening warehouse 4) Comprised of a material-storing installation, metering device, mixing unit, conveyer, baking channel, paper decoiling and wrapping installations, cross-cutter, roller supporter and material-loading system Specifications: 1) Width of foam plastic produced: 2m 2) Height of foam plastic produced: 1 – 1.3m, mainly depending on the length and technical requirement 3) Revolution speed of mixing head: 4,500, 5,000, 5,500r/min 4) Conveying speed: 0.6 - 6m/min 5) Flowing rate of mixing head: 225L/min 6) Production capacity: 4,000 – 5,000MT/year 7) Rated power: 110kW 8) External dimensions: 40.5 x 4.6 x 3.45m (not including storage tanks) 9) Weight: about 20MT
Product Origin:China
Brand Name:
Price Terms:
Payment Terms:
Certification:
Description:Product Name: Flat-Top Continuous Foaming Production LinePlace of Origin: ChinaFeatures: 1) PU production equipment 2) Polyether, TDI and auxiliary devices stored in loading tanks 3) Operation process: a) Raw materials delivered into mixing head in a certain ratio b) Transferred to overflowing vessel and an adjustable falling plate for conveying c) In the process of conveying, foaming mixed materials are heated to cure d) Guaranteeing continuous production, paper-decoiling and paper-wrapping installations are synchronous with foaming process e) Continuously foaming plastic shall be cut into required lengths and moved to the ripening warehouse 4) Comprised of a material-storing installation, metering device, mixing unit, conveyer, baking channel, paper decoiling and wrapping installations, cross-cutter, roller supporter and material-loading system Specifications: 1) Width of foam plastic produced: 2m 2) Height of foam plastic produced: 1 – 1.3m, mainly depending on the length and technical requirement 3) Revolution speed of mixing head: 4,500, 5,000, 5,500r/min 4) Conveying speed: 0.6 - 6m/min 5) Flowing rate of mixing head: 225L/min 6) Production capacity: 4,000 – 5,000MT/year 7) Rated power: 110kW 8) External dimensions: 40.5 x 4.6 x 3.45m (not including storage tanks) 9) Weight: about 20MT
