Fiber Media Converter
Product Description:
The Converters and Repeaters can be used to convert various optical fiber digital signals, such as Ethernet, ATM, SDH, and control signals etc. Using high efficiency conversion circuits, high quality IC chips, and high quality optical transceivers integrated module, the products are stable performance, good quality, and applicable to various environments of optical fiber digital transmission.
Two optical fiber interfaces (SC/ST/FC) of the Converter can achieve conversion of optical signals between multi/multimode optical fiber, between single/multimode fiber or between single/singlemode fiber. XM01 series converters: The max distance of multimode fiber is up to 2km, singlemode fiber is available from 20 to 120km; XM01 series converters: The max distance of 50um multimode fiber is up to 550 m, for 62.5um multimode fiber is up to 224 m, and single-mode fiber is available from 10 to 100km.
XM01XX can be used to convert 2~155Mbps optical digital signals, in which XX express fiber type. M is multimode; S is single mode.
XM01XX can be used to convert 100~1250Mbps optical digital signals, in which XX express fiber type. M is multimode; S is single mode.
Main features:
1. The conversion of optical signals can be carried out between multi/multimode optical fiber, between single/multimode fiber, or between single/single mode fiber.
2. Supporting conversion of 2~155Mbps or 100~1250Mbps optical digital signals.
Technical Specifications:
* Fiber Connector: Multitude ST/SC; Single mode SC/ST/FC
* Transmission Rate: CF01XX: 2~155Mbps; CG01XX: 100~1250Mbps
*Optical fiber:Multitude: 50/125, 62. 5/125um; Single mode: 8. 3/125, 8. 7/125, 9/125, 10/125um
* Power: External or Internal switching power: AC110~260V/DC5V
* Ambient temperature: 0 ~ +50º C
* Storage temperature: -20 ~ +70º C
* Humidity: 5% ~ 90%
