Double frequency ultrasonic transducer 38khz 80khz 50w with high effect and low heating for different cleaning machine
Quick Detail
double frequency ultrasonic transducer 38khz and 80khz 50w :
Piezoelectric transducer uses the piezoelectric effect to realize transduction between electric and sound energy. It comprises a radiation head, electrode, cap, prestressed bolt, piezoelectric chip and an insulating tube.
Multi Frequency Ultrasonic Transducer 50W Piezoelectric ultrasonic transducer
Description
double frequency ultrasonic transducer 38khz and 80khz 50w :
Features
◊ High efficiency: high mechanical parameter Q, the transduction efficient between electricity and sound above 95%.
◊ High amplitude: the transducer strength is improved by fixing the high speed vibrator directly on the base of washing groove with bolt. Compare with a magnetic expansion vibrator, its amplitude can be improved above 50%.
◊ Good heat resistance: a large range of working temperature, low resonance impedance and heat productivity.
◊ Good construction: fastened by bolt, easy for assembling, high reliability.
Applications of double frequency ultrasonic transducer 38khz and 80khz 50w :
widely used in ultrasonic cleaning machine and high-power industry cleaning devices.
Specifications
double frequency ultrasonic transducer 38khz and 80khz 50w :
|
Type |
Length (mm) |
Weigth(g) |
Frequency(khz) |
Resonance Impedance(Ω) |
Capacity(Pf)±10﹪ |
Power(w) |
|
CCH-4040D-38/80 KHZ P 4 |
61 |
330 |
38/80 |
<35 |
4800 |
50 |
Competitive Advantage of double frequency ultrasonic transducer 38khz and 80khz 50w :
◊ High efficiency
◊ High amplitude:
◊ Good heat resistance
◊ Good construction:
