Immersible Ultrasonic Transducer 40w 135khz For Automatic Ultrasonic Cleaner
Quick Detail
three frequency ultrasonic transducer 33khz 89khz 135khz 40w:
Piezoelectric transducer uses the piezoelectric effect to realize transduction between electric and sound energy. It comprises a radiation head, electrode, cap, prestressed bolt, piezoelectric chip and an insulating tube.
Description
three frequency ultrasonic transducer 33khz 89khz 135khz 40w:
◊ High efficiency: high mechanical parameter Q, the transduction efficient between electricity and sound above 95%.
◊ High amplitude: the transducer strength is improved by fixing the high speed vibrator directly on the base of washing groove with bolt. Compare with a magnetic expansion vibrator, its amplitude can be improved above 50%.
◊ Good heat resistance: a large range of working temperature, low resonance impedance and heat productivity.
◊ Good construction: fastened by bolt, easy for assembling, high reliability.
Applications
widely used in ultrasonic cleaning machine and high-power industry cleaning devices.
Specifications
three frequency ultrasonic transducer 33khz 89khz 135khz 40w:
|
Type |
Length (mm) |
Weigth(g) |
Frequency(khz) |
Resonance Impedance(Ω) |
Capacity (Pf)±10﹪ |
Power(w) |
|
CCH-4940D- 33/89/135KHZ P4 |
60 |
430 |
33/89/135 |
<30 |
5000 |
40 |
Competitive Advantage
three frequency ultrasonic transducer 33khz89khz135khz40w:
◊ High efficiency
◊ High amplitude:
◊ Good heat resistance
◊ Good construction:
