Ph5 Indoor Full Color LED Display

Model: EL-IF5-100
Display with cabinet:
Pixel pitch: 5mm
Pixel configuration: 1R1PG1B
Display resolution: 40000 pixels/sq.m
Cabinet size: 640mm*480mm*80mm
Viewing distance: not less than 4m
Environment temperature:
Working: -10 Centidegree -- +50 Centidegree Storage: -25 Centidegree -- +85 Centidegree Relative humidity: not more than 95%
Thickness of display: not more than 150mm+maintaining thickness(800mm)
Cabinet weight less than 25kg/unit

Power:
Working voltage: AC 220/110V(15% Tolerance)
Average consumption: 1100W/Sq.M
Max consumption: 1700 W/sq.m
Control system:
Mainframe: Pentium 3
Memory: not less than 256M
OS: WIN 98/WIN 2000/WIN NT
Control way: synchronism
VGA device: DVI

Main Parameter:
Driving Equipment: consant driving equpment only for LED products.
Driving way: Constant driving 1/8
Refresh frequency: not less than 400Hz
Frames change frequency: greater than 60Hz
Grey Scale: 4096 grades
Brightness: not less than 2000 nits
Mode of Brightness adjustment: through sorftware. in a range of 0-100 degree
Signal of Video: PAL/NTSC
Video Mode of output: DVI.VGA
Hardware for control system:DVI card/ Video processing unit+full color controling card
Communication distance:
Cat.5 communication cable(without relay)not over 130m;
Multi-mode optical fiber: 500m;
Single-mode optical fiber: 10km-20km
MTBF: not less than 10,000 hs
Lifespan: greater than 100,000 hs
Neat degree: Each pixel to the next one not more than 0.5mm;
Interstice between every two Neighboring module less than 1mm
Switching Power Supply: automatic switch
Mode of computer display: 1024*768p
Software for Playing: LED Studio
