12m High Q345 Hot rolled steel galvapole Street Lighting Pole 48mm Arm Diameter

FOB Price

US$ 30 - 300 / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	JSBS		Place of Origin	China
Model Number	Q235

Product Description

Delivery Time:within 15 working days
Certification:ISO9001 ISO14001 OHSAS18001

Double Arm Galvanized and Blue Powder Coated Highway Light Steel Pole

Material Reference
Applied to the material of general-purpose steel GB/T1591-2008, Q235, Q345, Q420, Q460 used in China.

Usually we use Q235 or Q345 for lighting poles.

Q235 = ASTM A36, SS400

Q345 = S355JR

Description:

Material:	Hot rolled steel, Q235,Q345
Yield strength of Material	Minimum yield strength>=235n/mm2 for Q235
Yield strength of Material	Minimum yield strength>=345n/mm2 for Q345
Pole’s height:	12m
Length of one part	Within 12m once forming
Wall thickness	2~15mm or more
Pole's Shape Available	Round, Polygonal, Taper Octagonal, Taper round, Round conical,Taper Square, Square.
Arm type can be made:	Double arm
Arm Diameter:	Diameter as 42mm, 48mm, 60mm, 76mm and etc, can fit to any diameter’s lamps.
Welding	Advanced submerge-arc welding and CNC welidng equipment. It has past flaw testing, internal and external double welding makes the welding beautiful in shape.
Manufacture Capacity	200 pcs /day
Wall thickness Tolerance	+- 0.1mm from 2.3mm to 4mm. +- 0.2mm from 5mm to 20mm. +- 0.5mm from 22mm to 30mm
Painting color	( RAL ) Color card or customized
Surface treatment 1	Hot dip Galvanized
Surface treatment 2	Hot dip galvanizing with power coating
Temperature range	-35 °C~+45 °C
Wind Speed:	Against wind pressure of 120Km/h to 180Km/h, according to client’s design.
Base plate mounted	Base plate is square, octagonal or round in shape with slotted holes for anchor bolt and dimension as per customer’s requirement.
Ground mounted:	The length buried underground as per customer’s requirement.
Quality Control	According to ISO9001-2008 requirements.
Other	Less land occupation & easy maintenance.

Manufacturing

Material preparation-flatting-cutting on the bias-bending-welding-repair and grinding-reforming-flushing-fix bottom plate-welding bottom plate-opening door-welding door strip,electric strip,and locking-bending arm-hot dip galvanization-plastic powder painted-inspection-shipment.

Welding penetration rate is above 95%.

Welding

Standard

Standard Title

Pole shafts&multi-sided tubular

Cross arms&all accessories

AWS D1.1/D1.1M:2010

Structural Welding Code-Steel

Welding wire

AWS D1.1/D1.1M:2010

Structural Welding Code-Steel

After the fabrication process as cutting plate, bending, forming, automatic welding, drilling holes, we get poles checked before galvanized, hot dip galvanized and powder coating and finally we get poles checked according to client's requirements.

Delivery
We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.

FAQ:
1. Port of Loading: Shanghai, China
2. Price term: EXW,FOB,CFR AND CIF.
3. Payment Term: 30%TT in deposit, 70%TT before shipment. Or LC.
4. Delivery: Based on your order quantity. Normally 15 days after receiving your deposit.
